DCEC QSZ13 Industrial Engine

DCEC  QSZ13 series Industrial engine is a 6-cylinders in line, 13 liter four-strokes engine with 130 mm bore and 163 mm stroke. DCEC  QSZ13 series Industrial engine equipped with Electrically Control High-pressure Common Rail. The prime power range of is 380 HP to 575 HP.

To achieve different output, DCEC  QSZ13 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC QSZ13 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC QSZ13 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

General Specifications of QSZ13 Series

Engine Type: 6 Cylinders, in Line
Displacement: 13 L
Rated Speed: 1900 RPM
Emission Standards: China Stage II / EU Stage III
Aspiration Method: TC & Charge Air Cooled
Advertised Power: 380 – 575 HP @ 1900 RPM
Peak Torque: 1900 – 2750 N·m @ 1100 – 1700 RPM
Bore * Stroke: 130 mm * 163 mm
Wet Weight: 1235 Kg
Dimension(L * W * H): N/A
DCEC QSZ13 Industrial Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

QSZ13-C380-III 380 HP @ 1900 RPM 1900 N.m @ 1100 RPM – 1500 RPM QSZ13-C400-III 400 HP @ 1900 RPM 2000 N.m @ 1100 RPM – 1400 RPM
QSZ13-C425-II 425 HP @ 1900 RPM 2250 N.m @ 1100 RPM – 1500 RPM QSZ13-C425-III 425 HP @ 1900 RPM 2100 N.m @ 1100 RPM – 1400 RPM
QSZ13-C450-II 450 HP @ 1900 RPM 2250 N.m @ 1100 RPM – 1500 RPM QSZ13-C450-III 450 HP @ 1900 RPM 2200 N.m @ 1200 RPM – 1400 RPM
QSZ13-C475-II 475 HP @ 1900 RPM 2400 N.m @ 1200 RPM – 1500 RPM QSZ13-C475-III 475 HP @ 1900 RPM 2200 N.m @ 1200 RPM – 1600 RPM
QSZ13-C500-II 500 HP @ 1900 RPM 2500 N.m @ 1200 RPM – 1500 RPM QSZ13-C500-III 500 HP @ 1900 RPM 2200 N.m @ 1200 RPM – 1700 RPM
QSZ13-C525-II 525 HP @ 1900 RPM 2580 N.m @ 1300 RPM – 1500 RPM QSZ13-C550-II 550 HP @ 1900 RPM 2650 N.m @ 1300 RPM – 1500 RPM
QSZ13-C575-II 575 HP @ 1900 RPM 2750 N.m @ 1300 RPM – 1500 RPM
——END——

DCEC QSZ13 Series Industrial Engine

This is the list of all series of DCEC  QSZ13 Series Industrial Engine.
Click here to find industrial engines by type (Fuel System & Emission Standard).

QSZ13-C380-III Industrial Engine

QSZ13-C380-III Industrial Engine

Rated Power: 380 HP @ 1900 RPM
Max. Torque: 1900 N.m @ 1100 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C400-III Industrial Engine

QSZ13-C400-III Industrial Engine

Rated Power: 400 HP @ 1900 RPM
Max. Torque: 1900 N.m @ 1100 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C425-II Industrial Engine

QSZ13-C425-II Industrial Engine

Rated Power: 425 HP @ 1900 RPM
Max. Torque: 2150 N.m @ 1100 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A

QSZ13-C425-III Industrial Engine

QSZ13-C425-III Industrial Engine

Rated Power: 425 HP @ 1900 RPM
Max. Torque: 2100 N.m @ 1100 RPM – 1400 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C450-II Industrial Engine

QSZ13-C450-II Industrial Engine

Rated Power: 450 HP @ 1900 RPM
Max. Torque: 2250 N.m @ 1100 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C450-III Industrial Engine

QSZ13-C450-III Industrial Engine

Rated Power: 450 HP @ 1900 RPM
Max. Torque: 2200 N.m @ 1200 RPM – 1400 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C475-II Industrial Engine

QSZ13-C475-II Industrial Engine

Rated Power: 475 HP @ 1900 RPM
Max. Torque: 2400 N.m @ 1200 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A

QSZ13-C475-III Industrial Engine

QSZ13-C475-III Industrial Engine

Rated Power: 475 HP @ 1900 RPM
Max. Torque: 2200 N.m @ 1200 RPM – 1600 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EU Stage III

QSZ13-C500-II Industrial Engine

QSZ13-C500-II Industrial Engine

Rated Power: 500 HP @ 1900 RPM
Max. Torque: 2500 N.m @ 1200 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: China Stage II

QSZ13-C500-III Industrial Engine

QSZ13-C500-III Industrial Engine

Rated Power: 500 HP @ 1900 RPM
Max. Torque: 2200 N.m @ 1200 RPM – 1700 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A

QSZ13-C525-II Industrial Engine

QSZ13-C525-II Industrial Engine

Rated Power: 525 HP @ 1900 RPM
Max. Torque: 2580 N.m @ 1300 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: N/A

QSZ13-C550-II Industrial Engine

QSZ13-C550-II Industrial Engine

Rated Power: 550 HP @ 1900 RPM
Max. Torque: 2650 N.m @ 1300 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: China Stage II

QSZ13-C575-II Industrial Engine

QSZ13-C575-II Industrial Engine

Rated Power: 575 HP @ 1900 RPM
Max. Torque: 2750 N.m @ 1300 RPM – 1500 RPM
Fuel System: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: China Stage II
