DCEC ISD4.5 Automotive Engine

DCEC ISD4.5 series automotive engine is a 4-cylinders in line, 4.5 liter four-strokes engine with 107 mm bore and 124 mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 140 HP to 220 HP.

As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

DCEC ISD4.5 series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC ISD4.5 electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.

If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

coming soon

coming soon

General Specifications of ISD4.5 Series

Engine Type: 4 Cylinders
Displacement: 4.5 L
Bore * Stroke:
107 mm * 124 mm
Advertised Power:
140 HP – 220 HP @ 2300 – 2700 RPM
Peak Torque:
450 – 820 N.m @ 800 -1700 RPM
Rated Speed: 2300 – 2700 RPM
Emission Standards:
Euro III – Euro VI
Aspiration Method: Turbocharged & Intercooler
Fuel System: Bosch HPCR
ISDe140 30 ISDe140 30140 HP
ISDe140-30B ISDe140-30B140 HP
ISDe140 41 ISDe140 41140 HP
ISD140 51 ISD140 51140 HP
ISDe160 30 ISDe160 30160 HP
ISDe160-30A SDe160-30A160 HP
ISDe160-30B ISDe160-30B160 HP
ISDe160 30-II ISDe160 30-II160 HP
ISDe160 31 ISDe160 31160 HP
ISDe160 41 ISDe160 41160 HP
ISD160 51 ISD160 51160 HP
ISDe180 30 ISDe180 30180 HP
ISDe180-30 ISDe180-30180 HP
ISDe180 30-II ISDe180 30-II180 HP
ISDe180 40 ISDe180 40180 HP
ISDe185-30A ISDe185-30A185 HP
ISDe185-30B ISDe185-30B185 HP
ISDe185 31 ISDe185 31185 HP
ISDe185 41 ISDe185 41185 HP
ISD185 51 ISD185 51185 HP
D4.5NS6B190 D4.5NS6B190190 HP
ISDe200-30 ISDe200-30200 HP
D4.5NS6B210 D4.5NS6B210210 HP
D4.5NS6B220 D4.5NS6B220220 HP

Engine Model

Power/HP

0 100 200 300 400 500 600 700
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
DCEC ISD4.5 Automotive Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

ISDe140 30 140 HP @ 2500 RPM 450 N.m @ 1400 RPM ISDe140-30B 140 HP @ 2500 RPM 450 N.m @ 800 ~ 1700 RPM
ISDe140 41 140 HP @ 2300 RPM 550 N.m @ 1100 ~ 1600 RPM ISD140 51 140 HP @ 2300 RPM 550 N.m @ 1100 ~ 1600 RPM
ISDe160 30 160 HP @ 2500 RPM 600 N.m @ 1400 RPM ISDe160-30A 160 HP @ 2700 RPM 600 N.m @ 1200 ~ 1700 RPM
ISDe160-30B 160 HP @ 2700 RPM 500 N.m @ 1100 ~ 1600 RPM ISDe160 30-II 160 HP @ 2700 RPM 500 N.m @ 1400 RPM
ISDe160 31 160 HP @ 2500 RPM 600 N.m @ 1200 RPM ISDe160 41 160 HP @ 2300 RPM 600 N.m @ 1100 ~ 1600 RPM
ISD160 51 160 HP @ 2300 RPM 600 N.m @ 1100 ~ 1600 RPM ISDe180 30 180 HP @ 2500 RPM 650 N.m @ 1400 RPM
ISDe180-30 180 HP @ 2700 RPM 650 N.m @ 1200 ~ 1700 RPM ISDe180 30-II 180 HP @ 2500 RPM 650 N.m @ 1400 RPM
ISDe180 40 180 HP @ 2500 RPM 700 N.m @ 1500 RPM ISDe185-30A 185 HP @ 2500 RPM 700 N.m @ 1400 RPM
ISDe185-30B 185 HP @ 2500 RPM 550 N.m @ 1400 RPM ISDe185 31 185 HP @ 2500 RPM 550 N.m @ 1400 RPM
ISDe185 41 185 HP @ 2300 RPM 700 N.m @ 1200 ~1600 RPM ISD185 51 185 HP @ 2300 RPM 700 N.m @ 1100 ~ 1600 RPM
D4.5NS6B190 190 HP @ 2300 RPM 700 N.m @ 1200 RPM ISDe200-30 200 HP @ 2700 RPM 550 N.m @ 1100 ~ 1700 RPM
D4.5NS6B210 210 HP @ 2300 RPM 760 N.m @ 1300 RPM D4.5NS6B220 220 HP @ 2300 RPM 820 N.m @ 1400 RPM
——END——

DCEC ISD4.5 Series Automotive Engine

This is the list of all series of DCEC ISD4.5 Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).

ISDe140 30 Automotive Engine Parts

ISDe140 30 Automotive Engine Parts

Rated Power: 140 HP @ 2500 RPM
Max. Torque: 450 N.m @ 1400 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III

ISDe140-30B Automotive Engine Parts

ISDe140-30B Automotive Engine Parts

Rated Power: 140 HP @ 2500 RPM
Peak Torque: 450 N.m @ 800-1700 RPM
Fuel Pump: HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EURO III

ISDe140 41 Automotive Engine

ISDe140 41 Automotive Engine

Rated Power: 140 HP @2300 rpm
Max. Torque: 550 N.m @1100~1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO IV

ISD140 51 Automotive Engine

ISD140 51 Automotive Engine

Rated Power: 140 HP @ 2300 rpm
Max. Torque: 550 N.m @ 1100-1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V

ISDe160 30 Automotive Engine Parts

ISDe160 30 Automotive Engine Parts

Rated Power: 160 HP @ 2700 rpm
Max. Torque: 600 N.m @ 1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III

ISDe160-30A Automotive Engine Parts

ISDe160-30A Automotive Engine Parts

Rated Power: 160 HP @ 2700 RPM
Peak Torque: 600 N.m @ 1200-1700 RPM
Fuel Pump: HPCR
Aspiration:TC & Air- Air Intercooler
Emission Standard: EURO III

ISDe160-30B Automotive Engine Parts

ISDe160-30B Automotive Engine Parts

Rated Power: 160 HP @ 2700 RPM
Peak Torque: 500 N.m @ 1100-1600 RPM
Fuel Pump: HPCR
Aspiration:TC & Air- Air Intercooler
Emission Standard: EURO III

ISDe160 30-II Automotive Engine Parts

ISDe160 30-II Automotive Engine Parts

Rated Power: 160 HP @ 2500 rpm
Max. Torque: 500 N.m @ 1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III

ISDe140 30 Automotive Engine Parts

ISDe160 31 Automotive Engine Parts

Rated Power: 160 HP @ 2500 rpm
Max. Torque: 600 N.m @1200 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III

ISDe140-30B Automotive Engine Parts

ISDe160 41 Automotive Engine

Rated Power: 160 HP @ 2300 rpm
Max. Torque: 600 N.m @ 1100~1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO IV

ISDe140-30B Automotive Engine Parts

ISD160 51 Automotive Engine

Rated Power: 160 HP @ 2300 rpm
Max. Torque: 600 N.m @ 1100-1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V

ISD140 51 Automotive Engine

ISDe180 30 Automotive Engine Parts

Rated Power: 180 HP @ 2500 RPM
Max. Torque: 650 N.m @ 1400 RPM
Fuel System: HPCR
Aspiration: TC & Air-Air
Emission Standard: EURO III

ISDe160 30 Automotive Engine Parts

ISDe180-30 Automotive Engine Parts

Rated Power: 180 HP @ 2700 RPM
Peak Torque: 650 N.m @ 1200-1700 RPM
Fuel Pump: HPCR
Aspiration:TC & Air-Air Intercooler
Emission Standard: EURO III

ISDe160-30A Automotive Engine Parts

ISDe180 30-II Automotive Engine Parts

Rated Power: 180 HP @ 2500 rpm
Max. Torque: 650 N.m @ 1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III

ISDe160 30-II Automotive Engine Parts

ISDe180 40 Automotive Engine

Rated Power: 180 HP @ 2500 rpm
Max. Torque: 700 N.m @ 1500 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO IV

ISDe140 30 Automotive Engine Parts

ISDe185-30A Automotive Engine Parts

Rated Power: 185 HP @ 2500 RPM
Peak Torque: 700 N.m @ 1400 RPM
Fuel Pump: HPCR
Aspiration:TC & Air-Air Intercooler
Emission Standard: Euro III

ISDe140-30B Automotive Engine Parts

ISDe185-30B Automotive Engine Parts

Rated Power: 185 HP @ 2500 RPM
Peak Torque: 550 N.m @ 1400 RPM
Fuel Pump: HPCR
Aspiration: Turbocharged & Air-Air Intercooler
Emission Standard: Euro Ⅲ

ISDe160-30A Automotive Engine Parts

ISDe185-31 Automotive Engine Parts

Rated Power: 185 HP @ 2500 RPM
Peak Torque: 550 N.m @ 1400 RPM
Fuel Pump: HPCR
Aspiration: Turbocharged & Air-Air Intercooler
Emission Standard: EURO III

ISDe160 30 Automotive Engine Parts

ISDe185 41 Automotive Engine

Rated Power: 185 HP @ 2300 rpm
Max. Torque: 700 N.m @ 1200-1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO IV

ISDe160-30A Automotive Engine Parts

ISD185 51 Automotive Engine

Rated Power: 185 HP @ 2300 rpm
Max. Torque: 700 N.m @ 1100-1600 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V

ISDe160 30 Automotive Engine Parts

D4.5NS6B190 Automotive Engine

Rated Power: 190 HP @ 2300 RPM
Max. Torque: 700 N.m @ 1100-1800 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO VI

ISDe160-30A Automotive Engine Parts

ISDe200-30 Automotive Engine

Rated Power: 200 HP @ 2700 RPM
Peak Torque: 550 N.m @ 1100-1700 RPM
Fuel Pump: HPCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO III

ISDe160 30-II Automotive Engine Parts

D4.5NS6B210 Automotive Engine

Rated Power: 210 HP @ 2300 RPM
Max. Torque: 760 N.m @ 1200-1800 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO VI

ISDe160-30B Automotive Engine Parts

D4.5NS6B220 Automotive Engine

Rated Power: 220 HP @ 2300 RPM
Max. Torque: 820 N.m @ 1300-1500 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO VI
