XCEC QSM11 Industrial Engine

XCEC QSM11 series Industrial engine is a 6-cylinders in line, 11 liter four-strokes engine with 125 mm bore and 147 mm stroke. XCEC QSM11 series Industrial engine equipped with Electrically Control High-pressure Common Rail. The prime power range of is 290 HP to400 HP.

To achieve different output, XCEC QSM11 series Industrial engine have three configurations which are turbocharged engine, turbocharge with water-air intercooler, turbocharge with air-air intercooler. In the detailed model name, code T means engine come with turbocharger, code single A means engine comes with water-air intercooler, and code double A means engine comes with air-air intercooler. As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
XCEC QSM11 series electronic industrial engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard XCEC QSM11 series electronic industrial engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at XCEC.

General Specifications of QSM11 Series

Engine Type: 6 Cylinders, in Line
Displacement: 11 L
Rated Speed: 1800 – 2100 RPM
Emission Standards: EU Stage II – IIIA
Aspiration Method: TC & Air-Air Intercooler
Advertised Power: 290 – 400 HP @ 1800 – 2100RPM
Peak Torque: 1424 – 1898 N.m @ 1400 RPM
Bore * Storke: 125 mm * 147 mm
Wet Weight: N/A
Dimension(L * W * H): N/A
QSM11-C290 QSM11-C290290 HP
QSM11-C290-II QSM11-C290-II290 HP
QSM11-C300 QSM11-C300300 HP
QSM11-C300-II QSM11-C300-II300 HP
QSM11-C300-III QSM11-C300-III300 HP
QSM11-C315 QSM11-C315315 HP
QSM11-C330 QSM11-C330330 HP
QSM11-C335 QSM11-C335335 HP
QSM11-C335-II QSM11-C335-II335 HP
QSM11-C335-III QSM11-C335-III335 HP
QSM11-C335-IV QSM11-C335-IV335 HP
QSM11-C335-V QSM11-C335-V335 HP
QSM11-C340 QSM11-C340340 HP
QSM11-C345 QSM11-C345345 HP
QSM11-C350A QSM11-C350A350 HP
QSM11-C350B QSM11-C350B350 HP
QSM11-C350-II QSM11-C350-II335 HP
QSM11-C360 QSM11-C360360 HP
QSM11-C360A QSM11-C360A268 HP
QSM11-C360B QSM11-C360B360 HP
QSM11-C375 QSM11-C375375 HP
QSM11-C375-II QSM11-C375-II375 HP
QSM11-C375-III QSM11-C375-III375 HP
QSM11-C385 QSM11-C385385 HP
QSM11-C400 QSM11-C400400 HP
QSM11-C400-II QSM11-C400-II400 HP
QSM11-C400-III QSM11-C400-III400 HP
QSM11-C400-IV QSM11-C400-IV400 HP
QSM11-C400-V QSM11-C400-V400 HP
QSM11-C400-VI QSM11-C400-VI400 HP
QSM11-C400-VII QSM11-C400-VII400 HP
QSM11-C400-VIII QSM11-C400-VIII400 HP
QSM11-C400-IX QSM11-C400-IX400 HP
QSM11-C420 QSM11-C420410 HP

Engine Model

Power/HP

260 300 330 340 350 360 390 410
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ
XCEC QSM11 Industrial Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

QSM11-C290 290 HP @ 2100 RPM 1478 N.m @ 1400 RPM QSM11-C290-II 290 HP @ 2100 RPM 1478 N.m @ 1400 RPM
QSM11-C300 300 HP @ 2100 RPM 1424 N.m @ 1400 RPM QSM11-C300-II 300 HP @ 2000 RPM 1575 N.m @ 1400 RPM
QSM11-C300-III 300 HP @ 2000 RPM 1424 N.m @ 1400 RPM QSM11-C315 315 HP @ 2100 RPM 1579 N.m @ 1400 RPM
QSM11-C330 330 HP @ 2100 RPM 1674 N.m @ 1400 RPM QSM11-C335 335 HP @ 2100 RPM 1674 N.m @ 1400 RPM
QSM11-C335-II 335 HP @ 2100 RPM 1674 N.m @ 1400 RPM QSM11-C335-III 335 HP @ 2000 RPM 1790 N.m @ 1300 RPM
QSM11-C335-IV 335 HP @ 2100 RPM 1674 N.m @ 1400 RPM QSM11-C335-V 335 HP @ 2100 RPM 1674 N.m @ 1400 RPM
QSM11-C340 340 HP @ 1800 RPM 1708 N.m @ 1400 RPM QSM11-C345 345 HP @ 1900 RPM 1710 N.m @ 1400 RPM
QSM11-C350A 350 HP @ 2100 RPM 1776 N.m @ 1400 RPM QSM11-C350B 350 HP @ 2000 RPM 1830 N.m @ 1400 RPM
QSM11-C350-II 350 HP @ 2000 RPM 1830 N.m @ 1400 RPM QSM11-C360 360 HP @ 1800 RPM 1710 N.m @ 1400 RPM
QSM11-C360A 268 HP @ 1800 RPM 1708 N.m @ 1400 RPM QSM11-C360B 360 HP @ 2100 RPM 1830 N.m @ 1400 RPM
QSM11-C375 375 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C375-II 375 HP @ 2000 RPM 1898 N.m @ 1300 RPM
QSM11-C375-III 375 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C385 385 HP @ 1900 RPM 1835 N.m @ 1400 RPM
QSM11-C400 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C400-II 400 HP @ 2000 RPM 1898 N.m @ 1300 RPM
QSM11-C400-III 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C400-IV 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM
QSM11-C400-V 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C400-VI 400 HP @ 2000 RPM 1898 N.m @ 1400 RPM
QSM11-C400-VII 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C400-VIII 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM
QSM11-C400-IX 400 HP @ 2100 RPM 1898 N.m @ 1400 RPM QSM11-C420 410 HP @ 1900 RPM 1898 N.m @ 1400 RPM
——END——

XCEC QSM11 Series Industrial Engine

This is the list of all series of XCEC QSM11 Series Industrial Engine.
Click here to find industrial engines by type (Fuel System & Emission Standard).

QSM11-C290 Industrial Engine

QSM11-C290 Industrial Engine

Rated Power:290 HP @ 2100 RPM
Max. Torque: 1478 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C290-II Industrial Engine

Rated Power:290 HP @ 2100 RPM
Max. Torque: 1478 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C300 Industrial Engine

QSM11-C300 Industrial Engine

Rated Power: 300 HP @ 2100 RPM
Max. Torque: 1424 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C300-II Industrial Engine

Rated Power: 300 HP @ 2000 RPM
Max. Torque: 1575 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C300 Industrial Engine

QSM11-C300-III Industrial Engine

Rated Power: 300 HP @ 2100 RPM
Max. Torque: 1424 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C315 Industrial Engine

Rated Power: 315 HP @ 2100 RPM
Max. Torque: 1424 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage II

QSM11-C290 Industrial Engine

QSM11-C330 Industrial Engine

Rated Power: 330 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C335 Industrial Engine

Rated Power: 335 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C335-II Industrial Engine

Rated Power: 335 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: T & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C335-III Industrial Engine

Rated Power: 335 HP @ 2000 RPM
Max. Torque: 1790 N.m @ 1300 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: China Stage 3

QSM11-C300 Industrial Engine

QSM11-C335-IV Industrial Engine

Rated Power: 335 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C300 Industrial Engine

QSM11-C335-V Industrial Engine

Rated Power: 335 HP @ 2100 RPM
Max. Torque: 1674 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C340 Industrial Engine

Rated Power: 340 HP @ 1800 RPM
Max. Torque: 1708 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C345 Industrial Engine

Rated Power: 345 HP @ 1900 RPM
Max. Torque: 1710 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: MEP Stage III

QSM11-C290 Industrial Engine

QSM11-C350A Industrial Engine

Rated Power: 350HP @ 2100RPM
Max. Torque: 1776N.m @ 1400RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C350B Industrial Engine

Rated Power: 350 HP @ 2000 RPM
Max. Torque: 1830 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C350-II Industrial Engine

Rated Power: 350 HP @ 2000 RPM
Max. Torque: 1830 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C360 Industrial Engine

Rated Power: 360 HP @ 1800 RPM
Max. Torque: 1708 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C360A Industrial Engine

Rated Power: 360 HP @ 1800 RPM
Max. Torque: 1708 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C360B Industrial Engine

Rated Power: 360 HP @ 2100 RPM
Max. Torque: 1830 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C375 Industrial Engine

Rated Power: 375 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C375-II Industrial Engine

Rated Power: 375 HP @ 2000 RPM
Max. Torque: 1898 N.m @ 1300 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: China Stage 3

QSM11-C290 Industrial Engine

QSM11-C375-III Industrial Engine

Rated Power: 375 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C385 Industrial Engine

Rated Power: 385 HP @ 2100 RPM
Max. Torque: 1424 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400 Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-II Industrial Engine

Rated Power: 400 HP @ 2000 RPM
Max. Torque: 1898 N.m @ 1300 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: China MEP CS III

QSM11-C290 Industrial Engine

QSM11-C400-III Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-IV Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-V Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-VI Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-VII Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-VIII Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C290 Industrial Engine

QSM11-C400-IX Industrial Engine

Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: EU Stage IIIA

QSM11-C300 Industrial Engine

QSM11-C420 Industrial Engine

Rated Power: 410 HP @ 1900 RPM
Max. Torque: 1898 N.m @ 1400 RPM
Fuel System: Celect Elec.
Aspiration: Turbocharged & CAC
Emission Standard: MEP Stage III

Global Activity

WhatsApp Online logo

Sales Team


DuraMac ManagerWhatApp-Icon

DuraMac SalesWhatApp-Icon

Generator-SinoGenWhatApp-Icon

EV System-EVMacWhatApp-Icon

Parts-PartMacWhatApp-Icon


Sales Manager-Mrs.Wendy FuWhatApp-Icon

Sales Director-Mr.Jasper Lee WhatApp-Icon

Shipping ServiceWhatApp-Icon

Contact EMAC Now!

Subscribe To Our Newsletter

Subscribe to get the latest updates from www.dcec-parts.com

Welcome on board, we will keep you updated with latest news and business activities!

Pin It on Pinterest
