DCEC C Automotive Engine
DCEC C series automotive engine is a 6-cylinders in line, 8.9 liter four-strokes engine with 114 mm bore and 135 mm stroke. Equipped with BYC (or Bosch or Weifu) pump, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 220 HP to 325 HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC C series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC C electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of C Series
| Engine Type: | 6 Cylinders |
| Displacement: | 8.3 L |
| Bore * Stroke: |
114 mm * 135 mm |
| Advertised Power: |
220 – 325 HP @ 2200 – 2500 RPM |
| Peak Torque: |
640 – 1175 N.m @ 1200 – 1500 RPM |
| Rated Speed: | 2200 – 2500 RPM |
| Emission Standards: |
Euro I / EURO II / EURO III |
| Aspiration Method: | Turbocharged & Air Intercooler |
| Wet Weight: | 636-776 kg |
| Dimension(L* W * H): | 1180 mm * 920 mm * 1280 mm |
| C220-10A220 HP | ||||||||
| C220-10B220 HP | ||||||||
| C230-10230 HP | ||||||||
| C230-20230 HP | ||||||||
| C240-10240 HP | ||||||||
| C245-20A241 HP | ||||||||
| C245-20B243 HP | ||||||||
| C260-20260 HP | ||||||||
| C260-33260 HP | ||||||||
| C280-20280 HP | ||||||||
| C300-20A280 HP | ||||||||
| C300-20B300 HP | ||||||||
| C325-20325 HP | ||||||||
|
Engine Model Power/HP |
220 | 230 | 240 | 245 | 260 | 280 | 300 | 325 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| C220-10A | 220 HP @ 2400 RPM | 780 N.m @ 1500 RPM | C220-10B | 220 HP @ 2400 RPM | 800 N.m @ 1500 RPM | ||
| C230-10 | 230 HP @ 2400 RPM | 640 N.m @ 1300-1500 RPM | C240-10 | 240 HP @ 2400 RPM | 880 N.m @ 1500 RPM | ||
| C245-20A | 241 HP @ 2400 RPM | 1025 N.m @ 1400 RPM | C245-20B | 243 HP @ 2200 RPM | 1043 N.m @ 1400 RPM | ||
| C260-20 | 260 HP @ 2500 RPM | 1025 N.m @ 1300 RPM | C260-33 | 260 HP @ 2200 RPM | 1025 N.m @ 1400 RPM | ||
| C280-20 | 280 HP @ 2200 RPM | 1125 N.m @ 1400 RPM | C300-20A | 280 HP @ 2200 RPM | 1125 N.m @ 1200 RPM | ||
| C300-20B | 300 HP @ 2200 RPM | 1125 N.m @ 1400 RPM | C325-20 | 325 HP @ 2200 RPM | 1175 N.m @ 1400 RPM | ||
| ——END—— | |||||||
DCEC C Series Automotive Engine
This is the list of all series of DCEC C Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).
C220-10A Automotive Engine
Rated Power: 220 HP @ 2400 RPM
Max. Torque: 780 N.m @ 1500 RPM
Fuel System: BYC PB pump
Aspiration: TC & Air Intercooler
Emission Standard: EURO I
C220-10B Automotive Engine
Rated Power: 220 HP @ 2400 RPM
Max. Torque: 780 N.m @ 1500 RPM
Fuel System: BYC PB Pump
Aspiration: TC & Air Intercooler
Emission Standard: EURO I
C230-10 Automotive Engine
Rated Power: 230 BHP @ 2400 RPM
Max. Torque: 800 N.m @ 1500 RPM
Fuel System: BYC PB Pump
Aspiration: TC & Air Intercooler
Emission Standard: EURO I
C230-20 Automotive Engine Parts
Rated Power: 296 BHP @ 2200 RPM
Max. Torque: 1125 N.m @ 1400 RPM
Fuel System: Bosch P 7100 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
C240-10 Automotive Engine Parts
Rated Power: 240 BHP @ 2400 RPM
Max. Torque: 880 N.m @ 1500 RPM
Fuel System: BYC PB Pump
Aspiration: TC & Air Intercooler
Emission Standard: EURO I
C245-20A Automotive Engine Parts
Rated Power: 245 BHP @ 2200 RPM
Max. Torque: 1025 N.m @ 1400 RPM
Fuel System: Bosch P7100 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C245-20B Automotive Engine Parts
Rated Power: 245 HP @ 2200 RPM
Max. Torque: 1043 N.m @ 1400 RPM
Fuel System: Bosch PW 2000 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C260-20 Automotive Engine Parts
Rated Power: 260 HP @ 2200 RPM
Max. Torque: 1025 N.m @ 1300 RPM
Fuel System: BYC P 7100 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C260-33 Automotive Engine Parts
Rated Power: 260 HP @ 2200 RPM
Max. Torque: 1025 N.m @ 1300 RPM
Fuel System: Weifu PH Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO III
C280-20 Automotive Engine Parts
Rated Power: 280 HP @ 2200 RPM
Max. Torque: 1150 N.m @ 1200-1700 RPM
Fuel System: Weifu PW 2000 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C300-20B Automotive Engine Parts
Rated Power: 300 HP @ 2200 RPM
Max. Torque: 1125 N.m @ 1200 RPM
Fuel System: Weifu PW 2000 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C300-20A Automotive Engine Parts
Rated Power: 300 HP @ 2200 RPM
Max. Torque: 1125 N.m @ 1200 RPM
Fuel System: Bosch P 7100 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
C325-20 Automotive Engine Parts
Rated Power: 325 HP @ 2200 RPM
Max. Torque: 1175 N.m @ 1400 RPM
Fuel System: Weifu PW 2000 Pump
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO II
