DCEC ISD6.7 Automotive Engine
DCEC ISD6.7series automotive engine is a 6-cylinders in line, 6.7 liter four-strokes engine with 107 mm bore and 124 mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 210 HP to 290 HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC ISD6.7 series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC ISD6.7 electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of ISD6.7 Series
| Engine Type: | 6 Cylinders |
| Displacement: | 6.7 L |
| Bore * Stroke: |
107 mm * 124 mm |
| Advertised Power: |
210 – 290 HP @ 2300-2500 RPM |
| Peak Torque: |
800 – 1100 N.m @ 1000 -1700 RPM |
| Rated Speed: | 2300-2500 RPM |
| Emission Standards: |
Euro III / Euro V/ Euro VI |
| Aspiration Method: | Turbocharged & Charge Air Cooled |
| Wet Weight: | 530 kg |
| Dimension(L * W * H): | 940 mm * 742 mm * 837 mm |
| ISDe210-30A210 HP | ||||||||
| ISDe210-30B210 HP | ||||||||
| ISDe230-30230 HP | ||||||||
| ISDe245-30245 HP | ||||||||
| D6.7NS6B260260 HP | ||||||||
| ISDe270-30A270 HP | ||||||||
| ISDe270-30B270 HP | ||||||||
| ISDe285-30285 HP | ||||||||
| ISDe285-50285 HP | ||||||||
| D6.7NS6B290290 HP | ||||||||
|
Engine Model Power/HP |
0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| ISDe210-30A | 210 HP @ 2500 RPM | 800 N.m @ 1400 RPM | ISDe210-30B | 210 HP @ 2500 RPM | 800 N.m @ 1200 – 1700 RPM | ||
| ISDe230-30 | 230 HP @ 2500 RPM | 900 N.m @ 1200-1700 RPM | ISDe245-30 | 245 HP @ 2500 RPM | 925 N.m @ 1200-1700 RPM | ||
| D6.7NS6B260 | 260 HP @ 2300 RPM | 1000 N.m @1000-1700 RPM | ISDe270-30A | 270 HP @ 2500 RPM | 970 N.m @ 1200 – 1700 RPM | ||
| ISDe270-30B | 270 HP @ 2500 RPM | 970 N.m @ 1200 – 1700 RPM | ISDe285-30 | 285 HP @ 2500 RPM | 970 N.m @ 1200 – 1700 RPM | ||
| ISDe285-50 | 285 HP @ 2500 RPM | 1020 N.m @ 1200-1700 RPM | D6.7NS6B290 | 290 HP @ 2300 RPM | 1100 N.m @1100-1600 RPM | ||
| ——END—— | |||||||
DCEC ISD6.7 Series Automotive Engine
This is the list of all series of DCEC ISD6.7 Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).
ISDe210-30A Automotive Engine Parts
Rated Power: 210 HP @ 2500 RPM
Max. Torque: 800 N.m @ 1400 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EURO Ⅲ
ISDe210-30B Automotive Engine Parts
Rated Power: 210 HP @ 2500 RPM
Max. Torque: 800 N.m @ 1200 – 1700 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage III
ISDe230-30 Automotive Engine Parts
Rated Power: 230 HP @ 2500 RPM
Max. Torque: 900 N.m @ 1200-1700 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EURO Ⅲ
ISDe245-30 Automotive Engine Parts
Rated Power: 245 HP @ 2500 RPM
Max. Torque: 925 N.m @ 1200-1700 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Charge Air Cooled
Emission Standard: EURO Ⅲ
D6.7NS6B260 Automotive Engine
Rated Power: 260 HP @ 2300 RPM
Max. Torque: 1000 N.m @1000-1700 RPM
Fuel Pump: HPCR
Aspiration: TC & Chatge Air Intercooler
Compression Ratio: 18.5:1
ISDe270-30A Automotive Engine Parts
Rated Power: 270 HP @ 2500 RPM
Max. Torque: 970 N.m @ 1200 – 1700 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage III
ISDe270-30B Automotive Engine Parts
Rated Power: 270 HP @ 2500 RPM
Max. Torque: 970 N.m @ 1200 – 1700 RPM
Fuel Pump: HPCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage III
ISDe285-30 Automotive Engine
Rated Power: 285 HP @ 2500 RPM
Max. Torque: 970 N.m @ 1200 – 1700 RPM
Fuel Pump: Bosch HPCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EU Stage III
ISDe285-50 Automotive Engine
Rated Power: 285 HP @ 2500 RPM
Max. Torque: 1100 N.m @ 1200 – 1700 RPM
Fuel Pump: Bosch HPCR
Aspiration:TC & Air-Air Intercooler
Emission Standard: Euro V
D6.7NS6B290 Automotive Engine
Rated Power: 290 HP @ 2300 RPM
Max. Torque: 1100 N.m @ 1100-1600 RPM
Fuel Pump: HPCR
Aspiration: TC & Chatge Air Intercooler
Compression Ratio:18.5:1
