DCEC ISL8.9 Automotive Engine
DCEC ISL8.9 series automotive engine is four-strokes engine with 114 mm bore and 145 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 270 HP to 400 HP.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
DCEC ISL8.9 series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC ISL8.9 electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.
General Specifications of ISL8.9 Series
| Engine Type: | 6 Cylinders |
| Displacement: | 8.9 L |
| Bore * Stroke: |
114 mm * 145 mm |
| Advertised Power: |
270 – 400 HP @ 2100 RPM |
| Peak Torque: |
1050 – 1700 N.m @ 1100 -1700 RPM |
| Rated Speed: | 2100 RPM |
| Emission Standards: |
Euro III – Euro V |
| Aspiration Method: | Turbocharged & Intercooler |
| Wet Weight: | 680 kg |
| Dimension(L * W * H): | 1300 mm * 900 mm * 1200 mm |
| ISLe270 30270 HP | ||||||||
| ISLe290 30290 HP | ||||||||
| ISLe290-30290 HP | ||||||||
| ISLe290 40290 HP | ||||||||
| ISLe290 50290 HP | ||||||||
| ISLe292 40292 HP | ||||||||
| ISLe292 50292 HP | ||||||||
| ISLe310 30310 HP | ||||||||
| ISLe310-30310 HP | ||||||||
| ISLe315 40315 HP | ||||||||
| ISLe315 50315 HP | ||||||||
| ISLe325 40325 HP | ||||||||
| ISLe325 50325 HP | ||||||||
| ISLe340 30340 HP | ||||||||
| ISLe340-30340 HP | ||||||||
| ISLe340 40340 HP | ||||||||
| ISLe340 50340 HP | ||||||||
| ISLe360 40360 HP | ||||||||
| ISLe360 50360 HP | ||||||||
| ISLe375 30375 HP | ||||||||
| ISLe375 30-II375 HP | ||||||||
| ISLe375-30375 HP | ||||||||
| ISLe375 40375 HP | ||||||||
| ISLe375 50375 HP | ||||||||
| ISLe380 50380 HP | ||||||||
| ISLe400 40400 HP | ||||||||
| ISL8.9-292E50A292 HP | ||||||||
| ISL8.9-315E50A315 HP | ||||||||
| ISL8.9-340E51A340 HP | ||||||||
| ISL8.9E5280B280 HP | ||||||||
| ISL8.9E5320B320 HP | ||||||||
| ISL8.9E5340B340 HP | ||||||||
|
Engine Model Power/HP |
0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
||
| ISLe270 30 | 270 HP @ 2100 RPM | 1050 N.m @ 1000-1900 RPM | ISLe290 30 | 290 HP @ 2100 RPM | 1050 N.m @ 1000 – 1900 RPM | ||
| ISLe290-30 | 290 HP @ 2100 RPM | 1050 N.m @ 1000-1900 RPM | ISLe290 40 | 290 HP @ 2100 RPM | 1050 N.m @ 1400 RPM | ||
| ISLe290 50 | 290 HP @ 2100 RPM | 1055 N.m @ 1100-1700 RPM | ISLe292 40 | 292 HP @ 2100 RPM | 1200 N.m @ 1400 RPM | ||
| ISLe292 50 | 292 HP @ 2100 RPM | 1055 N.m @ 1100-1700 RPM | ISLe310 30 | 310 HP @ 2100 RPM | 1200 N.m @ 1000-1700 RPM | ||
| ISLe310-30 | 310 HP @ 2100 RPM | 1200 N.m @ 1000-1700 RPM | ISLe315 40 | 315 HP @ 2100 RPM | 1200 N.m @ 1400 RPM | ||
| ISLe315 50 | 315 HP @ 2100 RPM | 1200 N.m @ 1100-1700 RPM | ISLe325 40 | 325 HP @ 2100 RPM | 1350 N.m @ 1400 RPM | ||
| ISLe325 50 | 325 HP @ 2100 RPM | 1350 N.m @ 1100-1500 RPM | ISLe340 30 | 340 HP @ 2100 RPM | 1425 N.m @ 1100-1400 RPM | ||
| ISLe340-30 | 340 HP @ 2100 RPM | 1425 N.m @ 1100-1400 RPM | ISLe340 40 | 340 HP @ 2100 RPM | 1425 N.m @ 1400 RPM | ||
| ISLe340 50 | 340 HP @ 2100 RPM | 1500 N.m @ 1200-1400 RPM | ISLe360 40 | 360 HP @ 2100 RPM | 1550 N.m @ 1400 RPM | ||
| ISLe360 50 | 360 HP @ 2100 RPM | 1550 N.m @ 1100-1400 RPM | ISLe375 30 | 375 HP @ 2100 RPM | 1550 N.m @ 1100-1400 RPM | ||
| ISLe375 30-II | 375 HP @ 2100 RPM | 1550 N.m @ 1100-1400 RPM | ISLe375-30 | 375 HP @ 2100 RPM | 1550 N.m @ 1100-1400 RPM | ||
| ISLe375-40 | 375 HP @ 2100 RPM | 1550 N.m @ 1400 RPM | ISLe375 50 | 375 HP @ 2100 RPM | 1550 N.m @ 1100-1500 RPM | ||
| ISLe380 50 | 380 HP @ 2100 RPM | 1700 N.m @ 1300-1400 RPM | ISLe400 40 | 400 HP @ 2100 RPM | 1700 N.m @ 1400 RPM | ||
| ISL8.9-292E50A | 292 HP @ 2100 RPM | 1150 N.m @ 1400 RPM | ISL8.9-315E50A | 315 HP @ 2100 RPM | 1190 N.m @ 1400 RPM | ||
| ISL8.9-340E51A | 340 HP @ 2100 RPM | 1500 N.m @ 1400 RPM | ISL8.9E5280B | 280 HP @ 2100 RPM | 1055 N.m @ 1100 RPM | ||
| ISL8.9E5320B | 320 HP @ 2500 RPM | 1350 N.m @ 1300 RPM | ISL8.9E5340B | 340 HP @ 2100 RPM | 1500 N.m @ 1300 RPM | ||
| ——END—— | |||||||
DCEC ISL8.9 Series Automotive Engine
This is the list of all series of DCEC ISL8.9 Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).
ISLe270 30 Automotive Engine Parts
Rated Power: 270 HP @ 2100 rpm
Max. Torque: 1050 N.m @ 1000-1900 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III
ISLe290 30 Automotive Engine Parts
Rated Power: 290 HP @ 2100 rpm
Max. Torque: 1050 N.m @ 1000 – 1900 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III
ISLe290-30 Automotive Engine Parts
Rated Power: 290 HP @ 2100 RPM
Max.Torque: 1050 N.m @ 1000-1900 RPM
Fuel System: CMS Common Rail System
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO III
ISLe290 40 Automotive Engine
Rated Power: 290 HP @ 2100 RPM
Max. Torque: 1050 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe290 50 Automotive Engine
Rated Power: 290 HP @ 2100 RPM
Max. Torque: 1055 N.m @ 1100-1700 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe292 40 Automotive Engine
Rated Power: 292 HP @ 2100 RPM
Max. Torque: 1200 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe292 50 Automotive Engine
Rated Power: 292 HP @ 2100 RPM
Max. Torque: 1055 N.m @1100-1700 rpm
Fuel System: Bosch HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe310 30 Automotive Engine Parts
Rated Power: 310 HP @ 2100 rpm
Max. Torque:1200 N.m @1000-1700 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III
ISLe310-30 Automotive Engine Parts
Rated Power: 310 HP @ 2100 RPM
Max.Torque: 1200 N.m @ 1000-1700 RPM
Fuel System: CCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro III
ISLe315 40 Automotive Engine
Rated Power: 315 HP @ 2100 RPM
Max. Torque: 1200 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe315 50 Automotive Engine
Rated Power: 315 HP @ 2100 RPM
Max. Torque: 1200 N.m @1100-1700 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe325 40 Automotive Engine
Rated Power: 320 HP @ 2100 RPM
Max. Torque: 1350 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe325 50 Automotive Engine
Rated Power: 325 HP @ 2100 RPM
Max. Torque: 1350 N.m @1100-1500 RPM
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe340 30 Automotive Engine Parts
Rated Power: 340 HP @ 2100 rpm
Max. Torque: 1425 N.m @ 1100 – 1400 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO III
ISLe340-30 Automotive Engine Parts
Rated Power: 340 HP @ 2100 RPM
Max.Torque: 1425 N.m @ 1100-1400 RPM
Fuel System: CMS Common Rail System
Aspiration: TC & Air-Air Intercooler
Emission Standard: Euro III
ISLe340 40 Automotive Engine
Rated Power: 340 HP @ 2100 RPM
Max. Torque: 1425 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO 4
ISLe340 50 Automotive Engine
Rated Power: 340 HP @ 2100 RPM
Max. Torque: 1500 N.m @1200-1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe360 40 Automotive Engine
Rated Power: 360 HP @ 2100 RPM
Max. Torque: 1550 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe360 50 Automotive Engine
Rated Power: 360 HP @ 2100 RPM
Max. Torque: 1550 N.m @1100-1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe375 30 Automotive Engine Parts
Rated Power: 375 HP @ 2100 RPM
Max.Torque: 1550 N.m @1100-1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO III
ISLe375-30 Automotive Engine Parts
Rated Power: 375 HP @ 2100 RPM
Max.Torque: 1550 N.m @ 1100-1400 RPM
Fuel System: CMS Common Rail System
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO III
ISLe375 30-II Automotive Engine Parts
Rated Power: 375 HP @ 2100 RPM
Max.Torque: 1550 N.m@1100-1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO III
ISLe375 40 Automotive Engine
Rated Power: 375 HP @ 2100 RPM
Max. Torque: 1550 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
ISLe375 50 Automotive Engine
Rated Power375 HP @ 2100 RPM
Max. Torque: 1550 N.m @1100-1500 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe380 50 Automotive Engine
Rated Power: 380 HP @ 2100 RPM
Max. Torque: 1700 N.m @1300-1400 rpm
Fuel System: HPCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
ISLe400 40 Automotive Engine
Rated Power: 400 HP @ 2100 RPM
Max. Torque: 1700 N.m @ 1400 RPM
Fuel System: CCR
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV
DCEC ISL8.9E5340B Automotive Engine
Rated Power: 340 HP @ 2100 rpm
Max. Torque: 1500 Nm @ 1300 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
DCEC ISL8.9E5320B Automotive Engine
Rated Power: 320 HP @ 2100 rpm
Max. Torque: 1350 Nm @ 1300 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
DCEC ISL8.9E5280B Automotive Engine
Rated Power: 280 HP @ 2100 rpm
Max. Torque: 1055 Nm @ 1100 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
DCEC ISL8.9-340E51A Automotive Engine
Rated Power: 340 HP @ 2100 rpm
Max. Torque: 1500 Nm @ 1400 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
DCEC ISL8.9-315E50A Automotive Engine
Rated Power: 315 HP@2100 rpm
Max. Torque: 1190 N.m@1400 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
DCEC ISL8.9-292E50A Automotive Engine
Rated Power: 292 HP @ 2100 rpm
Max. Torque: 1150 Nm @ 1400 rpm
Fuel System: CCR
Aspiration: TC & Water-Air Intercooler
Emission Standard: EURO V
