DCEC ISL9.5 Automotive Engine

DCEC ISL9.5 series automotive engine is a 6-cylinders in line, 9.5 liter four-strokes engine with 116.5 mm bore and 148 mm stroke. Equipped with Electrically Control High-pressure Common Rail, engine comes with turbocharger and Air- Air intercooler. The prime power range is from 290 HP to 425 HP.

As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

DCEC ISL9.5 series electronic automotive engine can reach upto EU Stage VI emission standard, the number 30/40/50/60 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V, VI. For different emission standard DCEC ISL9.5 electronic series automotive engine, the engine itself are the same, the major different are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.

If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

coming soon

coming soon

your 360 images

General Specifications of ISL9.5 Series

Engine Type: 6 Cylinders
Displacement: 9.5 L
Bore * Stroke:
116.5 mm * 148 mm
Advertised Power:
290 – 425 HP @ 1900 – 2000 RPM
Peak Torque:
1250 – 1810 N.m @ 1100 -1900 RPM
Rated Speed: 1900 – 2000 RPM
Emission Standards:
Euro III – Euro V
Aspiration Method: Turbocharged & Air-to-Air Cooling
Weight: 706-794 kg
Dimension(L * W * H): 1149 mm * 767 mm * 1105 mm
LK290 33 LK290 33290 HP
LK340 33 LK340 33340 HP
LK340 33-II LK340 33-II340 HP
ISL9.5-292E40A ISL9.5-292E40A292 HP
ISL9.5-292E40A-ll ISL9.5-292E40A-II292 HP
ISL9.5-292E42A ISL9.5-292E42A292 HP
ISL9.5-292E43A ISL9.5-292E43A292 HP
ISL9.5-315E40A ISL9.5-315E40A315 HP
ISL9.5-315E40A-ll ISL9.5-315E40A-ll315 HP
ISL9.5-315E43A ISL9.5-292E43A 315 HP
ISL9.5-325E40A ISL9.5-325E40A315 HP
ISL9.5-340E40A ISL9.5-340E40A340 HP
ISL9.5-340E40A-ll ISL9.5-340E40A-ll340 HP
ISL9.5-340E41A ISL9.5-340E41A340 HP
ISL9.5-340E42A ISL9.5-340E42A340 HP
ISL9.5-340E43A SL9.5-340E43A340 HP
ISL9.5-350E40A ISL9.5-325E40A350 HP
ISL9.5-350E40A-ll ISL9.5-350E40A-ll350 HP
ISL9.5-360E40A ISL9.5-360E40A360 HP
ISL9.5-375E40A ISL9.5-375E40A375 HP
ISL9.5-375E40A-II ISL9.5-375E40A-II375 HP
ISL9.5-375E42A ISL9.5-375E42A375 HP
ISL9.5-385E40A ISL9.5-385E40A385 HP
ISL9.5-385E40A-II ISL9.5-385E40A-II385 HP
ISL9.5-385E41A ISL9.5-385E41A385 HP
ISL9.5-385E51A ISL9.5-385E51A385 HP
ISL9.5-400E40A ISL9.5-400E40A400 HP
ISL9.5-400E40A-II ISL9.5-400E40A-II400 HP
ISL9.5-425E40A ISL9.5-425E40A425 HP

Engine Model

Power/HP

0 100 200 300 400 500 600 700
Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ



DCEC ISL9.5 Automotive Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

LK290 33 290 HP @ 2000 RPM 1350 N.m @ 1100 RPM LK340 33 340 HP @ 2000 RPM 1500 N.m @ 1300 RPM
LK340 33-II 340 HP @ 2000 RPM 1550 N.m  @ 1200-1300 RPM ISL9.5-292E40A 292 HP @ 1900 RPM 1200  N.m  @  1100-1700  RPM
ISL9.5-292E40A-ll 292 HP @ 1900 RPM 1200  N.m  @  1100-1700  RPM ISL9.5-292E42A 292 HP @ 1900 RPM 1350  N.m  @  1100-1500  RPM
ISL9.5-292E43A 292 HP @ 1900 RPM 1400  N.m  @  1200  RPM ISL9.5-315E40A 315 HP @ 1900 RPM 1250 N.m @ 1100-1700 RPM
ISL9.5-315E40A-ll 315 HP @ 1900 RPM 1250  N.m  @  1100-1700  RPM ISL9.5-315E43A 315 HP @ 1900 RPM 1500 N.m @ 1200 RPM
ISL9.5-325E40A 325 HP @ 1900 RPM 1400  N.m  @  1100-1500  RPM ISL9.5-340E40A 340 HP @ 1900 RPM 1500  N.m  @  1100-1500  RPM
ISL9.5-340E40A-ll 340 HP @ 1900 RPM 1500 N.m @ 1100-1500 RPM ISL9.5-340E41A 340 HP @ 1900 RPM 1500 N.m @ 1200 RPM
ISL9.5-340E42A 340 HP @ 1900 RPM 1500  N.m  @  1100-1500  RPM ISL9.5-340E43A 340 HP @ 1900 RPM 1620 N.m @ 1200 RPM
ISL9.5-350E40A 350 HP @ 1900 RPM 1500  N.m  @  1100-1600  RPM ISL9.5-350E40A-ll 350 HP @ 1900 RPM 1500 N.m @ 1100-1600 RPM
ISL9.5-360E40A 360 HP @ 1900 RPM 1600 N.m @ 1200-1500 RPM ISL9.5-375E40A 375 HP @ 1900 RPM 1620 N.m @ 1200-1500 RPM
ISL9.5-375E40A-II 375 HP @ 1900 RPM 1620 N.m @ 1200-1500 RPM ISL9.5-375E42A 375 HP @ 1900 RPM 1700 N.m @ 1200-1500 RPM
ISL9.5-385E40A 385 HP @ 1900 RPM 1600 N.m @ 1100-1700 RPM ISL9.5-385E40A-II 385 HP @ 1900 RPM 1600 N.m @ 1100-1500 RPM
ISL9.5-385E41A 385 HP @ 1900 RPM 1600 N.m @ 1200-1900 RPM ISL9.5-385E51A 385 HP @ 1900 RPM 1600 N.m @ 1200-1600 RPM
ISL9.5-400E40A 400 HP @ 1900 RPM 1710 N.m @ 1200-1400 RPM ISL9.5-400E40A-II 400 HP @ 1900 RPM 1710 N.m @ 1200-1400 RPM
ISL9.5-425E40A 425 HP @ 1900 RPM 1810 N.m @ 1300-1400 RPM
——END——

DCEC ISL9.5 Series Automotive Engine

This is the list of all series of DCEC ISL9.5 Series Automotive Engine.
Click here to find automotive engines by type (Fuel System & Emission Standard).

LK290 33 Automotive Engine

LK290 33 Automotive Engine

Rated Power: 290 HP @ 2000 RPM
Max. Torque: 1350 N.m @ 1100 RPM
Fuel System: HPCR
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO III

LK290 33 Automotive Engine

LK340 33 Automotive Engine

Rated Power: 340 HP @ 2000 RPM
Max. Torque: 1550 N.m @ 1200-1300 RPM
Fuel System: Weifu PH pump
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO III

LK340 33-II Automotive Engine

LK340 33-II Automotive Engine

Rated Power: 340 HP @ 2000 RPM
Max. Torque: 1500 N.m @ 1300 RPM
Fuel System: Weifu PH pump
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO III

LK340 33-II Automotive Engine

ISL9.5-292E40A Automotive Engine

Rated Power: 292 HP @ 1900 RPM
Max. Torque: 1200 N.m @ 1100 – 1700 RPM
Fuel System: HPCR
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: Euro IV

LK340 33-II Automotive Engine

ISL9.5-292E40A-II Automotive Engine

Rated Power: 292 HP @ 1900 RPM
Max. Torque: 1200 N.m @ 1100-1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & CAC
Emission Standard: Euro IV

LK340 33-II Automotive Engine

ISL9.5-292E42A Automotive Engine

Rated Power: 292 HP @ 1900 RPM
Max. Torque: 1200 N.m @ 1100-1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-292E43A Automotive Engine

Rated Power: 292 HP @ 1900 RPM
Max. Torque: 1400 N.m @ 1200 – 1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-315E40A Automotive Engine

Rated Power: 315 HP @ 1900 RPM
Max. Torque: 1250 N.m @ 1100 – 1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO VI

LK340 33-II Automotive Engine

ISL9.5-315E40A-II Automotive Engine

Rated Power: 315 HP @ 1900 RPM
Max. Torque: 1250 N.m @ 1100-1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-315E43A Automotive Engine

Rated Power: 315 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1200 – 1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-325E40A Automotive Engine

Rated Power: 325 HP @1900 RPM
Max. Torque: 1400 N.m @ 1100-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-340E40A Automotive Engine

Rated Power: 335 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1100 – 1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: Country VI

LK340 33-II Automotive Engine

ISL9.5-340E40A-II Automotive Engine

Rated Power: 340 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1100-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-340E41A Automotive Engine

Rated Power: 340 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1200 – 1900 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-340E42A Automotive Engine

Rated Power: 340 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1100-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-340E43A Automotive Engine

Rated Power: 340 HP @ 1900 RPM
Max. Torque: 1620 N.m @ 1200 – 1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-350E40A Automotive Engine

Rated Power: 350 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1100 – 1600 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-350E40A-II Automotive Engine

Rated Power: 350 HP @ 1900 RPM
Max. Torque: 1500 N.m @ 1100-1600 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & CAC
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-360E40A Automotive Engine

Rated Power: 360 HP @ 1900 RPM
Max. Torque: 1600 N.m @ 1200 – 1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-375E40A Automotive Engine

Rated Power: 375 HP @ 1900 RPM
Max. Torque: 1620 N.m @ 1200 – 1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-375E40A-II Automotive Engine

Rated Power: 375 HP @ 1900 RPM
Max. Torque: 1620 N.m @ 1200-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-375E42A Automotive Engine

Rated Power: 375 HP @ 1900 RPM
Max. Torque: 1700 N.m @ 1200-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-385E40A Automotive Engine

Rated Power: 385 HP @ 1900 RPM
Max. Torque: 1600 N.m @ 1100 – 1700 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-385E40A-II Automotive Engine

Rated Power: 385 HP @ 1900 RPM
Max. Torque: 1600 N.m @ 1100-1500 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-385E41A Automotive Engine

Rated Power: 385 HP @ 1900 RPM
Max. Torque: 1600 N.m @ 1200 – 1900 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharging & air-to-air cooling
Emission Standard: EURO IV

ISL9.5-385E51A Automotive Engine

ISL9.5-385E51A Automotive Engine

Rated Power: 385 HP @ 1900 RPM
Max. Torque: 1600 N.m @ 1200-1600 RPM
Fuel System: CFSW(HPCR)
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO V

ISL9.5-385E51A Automotive Engine

ISL9.5-400E40A Automotive Engine

Rated Power: 400 HP @ 1900 RPM
Max. Torque: 1710 N.m @ 1200-1400 RPM
Fuel System: CCR
Aspiration: TC & Air-Air Intercooler
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-400E40A-II Automotive Engine

Rated Power: 400 HP @ 1900 RPM
Max. Torque: 1710 N.m @ 1200-1400 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV

LK340 33-II Automotive Engine

ISL9.5-425E40A Automotive Engine

Rated Power: 425 HP @ 1900 RPM
Max. Torque: 1810 N.m @ 1300 – 1400 RPM
Fuel System: Kunpeng common rail system
Aspiration: Turbocharged & Charge Air Cooled
Emission Standard: EURO IV
