DCEC B5.9CMIII-GM Marine Auxiliary Engine

DCEC B5.9CMII-GM series marine auxiliary engine is a 6-cylinders in line, 5.9 liters four-strokes engine with 102mm bore and 120mm stroke. Equipped with BYC fuel pump. The prime power range of DCEC B5.9CMII-GM series marine auxiliary engine is 100 kW to 115 kW.

DCEC marine auxiliary engines have different configurations which have different power output. DCEC provides both heat exchanger cooling and radiator cooling marine auxiliary engines, which mainly using for marine main generator and marine emergency generator. For the emergency generator set applications, we provide additional options for customers such as dual starter motor system (we provide both electric and spring starter motor for customers), which are required by most of international classifications. All of DCEC marine auxiliary engine are comes with dry type exhaust system, which means dry type exhaust manifold and dry type turbocharger, SeaMac provides upgrading services for water-cooled exhaust system, which modify dry type exhaust system into water-cooled exhaust system, which are quite important and often requested by passenger boat projects.

Coming Soon

General Specifications of B5.9CMII-GM Series

Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore * Stroke: 102 mm*120 mm
Advertised Power: 100 – 115 kW @ 1500 RPM
Peak Torque: 636 – 732 N.m @ 1500 RPM
Rated Speed: 1500 RPM
Emissision: N/A
Aspiration Method: Turbocharged/Aftercooled
Wet Weight: 543 kg
Dimission Standards: N/A
DCEC B5.9CMII-GM Marine Auxiliary Engine Catalogue

Engine Model

Rated Power

Aspiration

Engine Model

Rated Power

Aspiration

B5.9CMII136G 100 kW @ 1500 RPM Turbocharged/Aftercooled B5.9CMII156G 115 kW @ 1500 RPM Turbocharged/Aftercooled
——END——

DCEC B5.9CMII-GM Series Marine Auxiliary Engine

This list including all models of DCEC B5.9CMII-GM Series Marine Auxiliary Engine.
