 DCEC 6LTAA8.9 Pump Drive Engine

DCEC 6LTAA8.9 series pump drive engine is a 6-cylinders in line, 8.9 liters four-strokes engine with 114 mm bore and 145mm stroke. DCEC 6LTAA8.9 series pump drive engine equipped with mechanical fuel pump and electronic governor. The prime power range of DCEC 6LTAA8.9 series pump drive engine is from 179 kW to 264 kW.

DCEC pump drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

DCEC 6LTAA8.9 series electronic pump drive engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC 6LTAA8.9 series electronic pump drive engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.

If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

General Specifications of 6LTAA8.9 Series

Engine Type: 6 Cylinders, in Line
Displacement: 8.9 L
Rated Speed: 1500 – 3000 RPM
Rated Power / Speed: 179 – 264 kW @ 1500 – 3000 RPM
Peak Torque: 1037 – 1464 N.m @ 1200 – 2200 RPM
Fuel System: Weifu PW2000 Pump / RSV Mechanical Governor
Aspiration Method: Turbocharged & Air-Air Intercooler
Bore * Stroke: 114 mm * 145 mm
Basic Enging(L * W * H): 1240 mm * 780 mm * 1185 mm
Dry Weight: 637 – 650 kg
DCEC 6LTAA8.9 Pump Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

6LTAA8.9-C240 179 kW @ 2200 RPM 1180 N·m @ 1400 RPM 6LTAA8.9-C260 194 kW @ 2200 RPM 1240 N·m @ 1200 RPM
6LTAA8.9-C300 225 kW @ 2000 RPM
1230 N·m @ 1400 RPM 6LTAA8.9-P310 230 kW @ 1500 RPM
1464 N.m @ 1500 RPM
6LTAA8.9-C325 239 kW @ 2200 RPM 1037 N·m @ 2200 RPM 6LTAA8.9-P340 255 kW @ 1800 RPM 1464 N.m @ 1500 RPM
6LTAA8.9-C340 250 kW @ 3000 RPM N/A 6LTAA8.9-C360 264 kW @ 2200 RPM 1400 N·m @ 1400 RPM
——END——

DCEC 6LTAA8.9 Series Pump Drive Engine

This list including all models of DCEC 6LTAA8.9 Series Pump Drive Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).

6LTAA8.9-C240 Pump Drive Engine

6LTAA8.9-C240 Pump Drive Engine

Rated Power: 179 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Air-Air Intercooler
Emission Standard: CHINA Il

6LTAA8.9-C240 Pump Drive Engine

6LTAA8.9-C260 Pump Drive Engine

Rated Power: 194 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Air-Air Intercooler
Emission Standard: CHINA Il

6LTAA8.9-C240 Pump Drive Engine

6LTAA8.9-C300 Pump Drive Engine

Rated Power: 225 kW @ 2000 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Air-Air Intercooler
Emission Standard: CHINA II

6LTAA8.9-C325 Pump Drive Engine

6LTAA8.9-C325 Pump Drive Engine

Rated Power: 239 kW @ 2200 RPM
Fuel Pump: Bosch P7100
Governor: RQV-K
Aspiration: TC & Air-Air Intercooler
Emission Standard: CHINA II

6LTAA8.9-C340 Pump Drive Engine

6LTAA8.9-C340 Pump Drive Engine

Rated Power: 250 kW @ 3000 RPM
Fuel Pump: Mechanical
Governor:RSV Mechanical
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A

6LTAA8.9-C360 Pump Drive Engine

6LTAA8.9-C360 Pump Drive Engine

Rated Power: 264 kW @ 2200 RPM
Fuel Pump: BYC P7100
Governor:RSV Mechanical
Aspiration: TC & Air-Air Intercooler
Emission Standard: N/A
