DCEC 6CTA8.3 Pump Drive Engine

DCEC 6CTA8.3 series pump drive engine is a 6-cylinders in line, 8.3 liters four-strokes engine with 114 mm bore and 135 mm stroke. DCEC 6CTA8.3 series pump drive engine equipped with mechanical fuel pump and electronic governor. The prime power range for 1500 RPMof DCEC 6CTA8.3 series pump drive engine is from 151 kW to 194 kW. The prime power range for 1800 RPM of DCEC 6CTA8.3 series pump drive engine is from 151 kW to 194 kW.

DCEC pump drive engines have different configurations which have different power output, with code T in the engine model name means turbocharged engine, code TA in the engine model means turbocharge with water-air intercooler and code TAA in the engine model means turbocharge with air-air intercooler. As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc. We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

DCEC 6CTA8.3 series electronic pump drive engine can reach upto EU Stage V emission standard, the number 30/40/50 are the emission standard mark of engine, which means engine emission standard are EU Stage III, IV, V. For different emission standard DCEC 6CTA8.3 series electronic pump drive engine, the engine itself are the same, the major different of different emission standard engine models are the after-treatment system and ECU program, EMAC will keep updating products introduction page of different emission standard engine models, welcome to subscribe our website to get latest update information.

If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at DCEC.

General Specifications of 6CTA8.3 Series

Engine Type: 6 Cylinders, in Line
Displacement: 8.3 L
Rated Speed: 1500 – 3000 RPM
Rated Power / Speed: 151 – 194 kW @ 1500 – 3000 RPM
Peak Torque: 900 – 1165 N.m @ 1300 – 1800 RPM
Fuel System: Weifu PW2000 / RSV Mechanical Governor
Aspiration Method: TC & Water-Air Intercooler
Bore * Stroke: 114 mm * 135 mm
Basic Engine(L * W * H): 1159 mm * 734 mm * 1153 mm
Wet Weight: 604 kg
DCEC 6CTA8.3 Pump Engine Catalogue

Engine Model

Rated Power

Peak Torque

Engine Model

Rated Power

Peak Torque

6CTA8.3-C205-II 151 kW @ 1850 RPM 900 N.m @ 1400 RPM 6CTA8.3-C215-II 160 kW @ 2200 RPM 908 N.m @ 1500 RPM
6CTA8.3-P220 163 kW @ 1500 RPM 1038 N.m @ 1500 RPM 6CTA8.3-C225 166 kW @ 3000 RPM N/A
6CTA8.3-P230 170 kW @ 1800 RPM 902 N.m @ 1800 RPM 6CTA8.3-C230-II 170 kW @ 1850 RPM 1000 N.m @ 1400 RPM
6CTA8.3-C240-II 179 kW @ 2200 RPM 1028 N.m @ 1500 RPM 6CTA8.3-C260-II 194 kW @ 1900 RPM 1150 N.m @ 1300 RPM
6CTAA8.3-C215 160 kW @ 2200 RPM 980 N.m @ 1500 RPM 6CTAA8.3-C240 179 kW @ 2200 RPM 1040 N.m @ 1400 RPM
6CTAA8.3-C248 183 kW @ 3000 RPM N/A 6CTAA8.3-P250 183 kW @ 1500 RPM 1165 N.m @ 1500 RPM
6CTAA8.3-P260 190 kW @ 1800 RPM 1008 N.m @ 1800 RPM 6CTAA8.3-C260 194 kW @ 2200 RPM 1100 N.m @ 1400 RPM
——END——



DCEC 6CTA8.3 Series Pump Drive Engine

This list including all models of DCEC 6CTA8.3 Series Pump Drive Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).

6CTA8.3-C205-II Pump Drive Engine

6CTA8.3-C205-II Pump Drive Engine

Rated Power: 151 kW @ 1850 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II

6CTA8.3-C215-II Pump Drive Engine

6CTA8.3-C215-II Pump Drive Engine

Rated Power: 160 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor:RSV Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II

6CTAA8.3-C215 Pump Drive Engine

6CTAA8.3-C215 Pump Drive Engine

Rated Power: 160 kW @ 2200 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Air-AirIntercooler
Emission Standard: Euro Stage II

6CTA8.3-C225 Pump Drive Engine

6CTA8.3-C225 Pump Drive Engine

Rated Power: 166 kW @ 3000 RPM
Fuel Pump: Mechanical
Governor:RSV Mechanical
Aspiration: Turbocharged & Intercooled
Emission Standard: N/A

6CTA8.3-C230-II Pump Drive Engine

6CTA8.3-C230-II Pump Drive Engine

Rated Power: 170 kW @ 1850 RPM
Fuel Pump: Weifu PW2000
Governor: Mechanical
Aspiration: TC & Water-AirIntercooler
Emission Standard: Euro Stage II

6CTA8.3-P230 Pump Drive Engine

6CTA8.3-P230 Pump Drive Engine

Rated Power: 170 kW @ 1800 RPM
Fuel Pump: Mechanical
Governor: Electronical
Aspiration: TC & Water-AirIntercooler
Emission Standard: N/A

6CTAA8.3-C248 Pump Drive Engine

6CTAA8.3-C248 Pump Drive Engine

Rated Power: 183 kW @ 3000 RPM
Fuel Pump: Mechanical
Governor:RSV Mechanical
Aspiration: Turbocharged & A-A Intercooled
Emission Standard: N/A

6CTAA8.3-C260 Pump Drive Engine

6CTAA8.3-C260 Pump Drive Engine

Rated Power: 194 kW @ 2200 RPM
Fuel Pump: BYC P7100
Governor: Mechanical
Aspiration: TC & Air-AirIntercooler
Emission Standard: Euro Stage II
