C230-20 Automotive Engine Parts

For the same model of engine, Cummins havedifferent SO (Shop Order) number, which have some tiny different to match therequirement from different customers, but most of the major components are thesame in the same model, so we randomly choose one of the SO number parts listto show on our website for your reference, if you need accurate parts list,please contact PartMac with your engine name plate, engine serial number orengine SO number, then our sales team will go back to you with parts catalogmatching to your engine. We provide maintenance manual, operation manual aswell technical support, we can also provide on-site engineer services to do therepair and maintenance works if customers pay all the relevant costs, pleasefeel free to contact us if you have any other questions.

Technical Specifications

Engine Model:	C230-20
Engine Type:	6
Displacement:	8.3 L
Rated Speed:	2200 RPM
Rated Power / Speed:	230 HP @ 2200 RPM
Peak Torque:	861 N.m @ 1300 RPM
Fuel System:	PW 2000 Pump
Aspiration Method:	Turbocharged & Air Intercooler
Emission Standard:	N/A
*Bore Stroke:**	114 mm * 135 mm
*Packing Size(L W * H):**	N/A
Wet Weight:	636 kg
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T ,L/C

coming soon

Search by Part No. or Part Name

Click Kit Name to Check Part List

AID,AIR HEATER STARTING
NO	Part No	Part Name	QTY	REMARKS
1	C3908110	PLUG,THREADED	1	—
2	C3930319	WASHER,INSULATING	1	—
3	C3930320	SCREW,HEX FLANGE HEAD CA	1	—
4	C4942815	HEATER,INTAKE AIR	1	—
5	C4980120	TAG,INSTRUCTION	1	—
6	D3936993	GASKET,INT MANIFOLD	1	—
——END——

APPROVAL,AGENCY
NO	Part No	Part Name	QTY	REMARKS
1	C3415394	SCREW,DRIVE	2	—
2	C4992258	DATAPLATE	1	—
——END——

PLUMBING,CY BLK IBC
NO	Part No	Part Name	QTY	REMARKS
1	C3678921	PLUG，THREADED	1	—
2	C3678912	SEAL,O RING	1	—
3	C3678922	PLUG，THREADED	1	—
4	C3678923	PLUG,THREADED	4	—
——END——

BLOCK,ENGINE
NO	Part No	Part Name	QTY	REMARKS
1	C3008468	PLUG,PIPE	1	—
2	C3008470	PLUG,PIPE	1	—
3	C3900257	DOWEL, PIN	2	—
4	C3901846	DOWEL,PIN	4	—
5	C3901969	PLUG，EXPANSION	1	—
6	C3907177	SEAL，RECTANGULAR	6	—
7	C3904483	DOWEL, PIN	1	—
8	C3917320	CRANKSHAFT,ENGINE	1	—
9	C3918776	GEAR，CRANKSHAFT	1	—
10	C3926048	SEAL，O RING	1	—
11	C3928031	NOZZLE,PISTON COOLING	12	—
12	C3931623	TAPPET,VALVE	12	—
13	C3939313	BLOCK,CYLINDER	1	—
14	C143066	PLUG，EXPANSION	2	—
15	C3004258	PLUG,EXPANSION	4	—
16	C3905401	PLUG,EXPANSION	4	—
17	C3916369	SCREW，HEX FLANGE HEAD	14	—
18	C3936058	CAP，MAIN BEARING	7	—
19	C3945329	BUSHING,CAMSHAFT	7	—
20	C3944153	BEARING,MAIN	7	—
21	C3944158	BEARING,MAIN	6	—
22	C3944163	BEARING,THRUST	1	—
23	C3948095	LINER，CYLINDER	6	—
24	CS 923 E	DRAINCOCK	1	—
——END——

PLUMBING,CYL BLK COOLANT
NO	Part No	Part Name	QTY	REMARKS
1	C3008469	PLUG,PIPE	2	—
——END——

HOUSING，FRONT GEAR
NO	Part No	Part Name	QTY	REMARKS
1	C3907998	SCREW,ROUND HEAD CAP	2	—
2	C3913995	HOUSING,TIMING PIN	1	—
3	C3903924	PIN,TIMING	1	—
4	C3904849	RING,RETAINING	1	—
5	C3913994	SEAL，O RING	1	—
6	C3919683	HOUSING,TIMING PIN	1	—
7	C3915772	SEAL，RECTANGLE	1	—
8	C3926846	SCREW,HEX FLANGE HEAD CA	3	—
9	C3938086	HOUSING,GEAR	1	—
10	C3943885	SCREW，HEX FLANGE HEAD	3	—
11	C3944293	GASKET,GEAR HOUSING	1	—
——END——

BREATHER,CRANKCASE
NO	Part No	Part Name	QTY	REMARKS
1	C3901249	SCREW,HEX FLANGE HEAD	1	—
2	C3907741	CLIP	1	—
3	C3909669	TUBE,BREATHER	1	—
4	C3912072	SCREW,SELF TAPPING MET	1	—
5	C3918616	HOSE,PLAIN	1	—
6	C3930827	HOSE，PLAIN	1	—
7	C3935113	CONNECTION,VENT	1	—
8	C3936331	SEAL，RECTANGULAR RING	1	—
9	C3970886	GASKET,BREATHER	1	—
10	C3991306	SCREW HEX FLANGE HEAD	6	—
11	C4940384	PLATE,COVER	1	—
12	C70622	CLIP	1	—
13	D3937613	CLAMP,HOSE	2	—
14	Q67226	CLAMP,SPRING HOST	1	—
——END——

PLUMBING,CPR COOLANT
NO	Part No	Part Name	QTY	REMARKS
1	C3415327	ELBOW,MALE ADAPTER	2	—
2	C3970801	TUBE,WATER INLET	1	—
3	C3970803	TUBE,CPR WATER OUTLET	1	—
——END——

COMPRESSOR,REFRIGERANT
NO	Part No	Part Name	QTY	REMARKS
1	C3902460	SCREW，HEX FLANGE HEAD	4	—
2	C3906621	SCREW,HEXAGON HEAD CAP	3	—
3	C3906621	SCREW,HEXAGON HEAD CAP	1	—
4	C3967107	WASHER,PLAIN	8	—
5	C3967108	WASHER,SPRING	4	—
6	C3967111	BRACKET,REF COMPRESSOR	1	—
7	C3970423	COMPRESSOR,REFRIGERANT	1	—
8	C4991552	NUT,REGULAR HEXAGON	4	—
——END——

DRIVE,REF COMPRESSOR
NO	Part No	Part Name	QTY	REMARKS
1	C3902114	SCREW,HEX FLANGE HEAD CA	3	—
2	C3979425	BELT,V RIBBED	1	—
3	C4936663	TENSIONER,BELT	1	—
——END——

PLUMBING,COO HTR STG AID
NO	Part No	Part Name	QTY	REMARKS
1	C3008469	PLUG,PIPE	1	—
——END——

CLUTCH,REAR
NO	Part No	Part Name	QTY	REMARKS
1	C3967119	WASHER,SPRING	8	—
2	C3967127	STUD	8	—
3	C3967128	NUT,REGULAR HEXAGON	8	—
4	C3968253	PLATE,CLUTCH PRESSURE	1	—
5	C3968254	DISC,CLUTCH	1	—
——END——

CLUTCH,REAR
NO	Part No	Part Name	QTY	REMARKS
1	Z*60205	BEARING,MAIN	1	—
——END——

COMPRESSOR，AIR
NO	Part No	Part Name	QTY	REMARKS
1	C3415333	ELBOW,MALE ADAPTER	1	—
2	C3415606	SPACER,MOUNTING	1	—
3	C3415607	GEAR,ACCESSORY DRIVE	1	—
4	C3903112	SCREW,HEX FLANGE HEAD CA	4	—
5	C3903210	NUT,HEXAGON FLANGE	2	—
6	C3934079	BRACE,AIR COMPRESSOR	1	—
7	C3937122	STUD	2	—
8	C3940245	GASKET,HYDRAULIC PUMP	1	—
9	C3970805	COMPRESSOR,AIR	1	—
10	C3976749	CONNECTOR,MALE	1	—
11	C4946716	HOSE,FLEXIBLE	1	—
12	C4991495	SCREW,HEX FLANGE HEAD CA	2	—
——END——

DAMPER,VIBRATION
NO	Part No	Part Name	QTY	REMARKS
1	C3906733	SCREW,HEX FLANGE HEAD	4	—
2	C3925567	DAMPER,VIBRATION	1	—
——END——

ACCESSORIES,ELECTRICAL
NO	Part No	Part Name	QTY	REMARKS
1	C3903990	SCREW,HEX FLANGE HEAD	1	—
2	C4932506	WIRE,GROUND	1	—
——END——

THERMOSTAT
NO	Part NO	Part Name	QTY	REMARKS
1	C3968559	THERMOSTAT	1	——
——END——

DOCUMENTATIO,ENG IDT
NO	Part NO	Part Name	QTY	REMARKS
1	C3974406	TAG,IDENTIFICATI	1	——
2	C3975443	COVER,PROTECTIVE	1	——
——END——

ALTERNATOR
NO	Part NO	Part Name	QTY	REMARKS
1	C3979372	ALTERNATOR	1	——
——END——

MOUNTING,ALTERNATOR
NO	Part NO	Part Name	QTY	REMARKS
1	C3415692	BRACKET,ALTERNATOR	1	——
2	C3901249	SCREW,HEX FLANGE HEAD	1	——
3	C3902460	SCREW，HEX FLANGE HEAD	1	——
4	C3903112	SCREW,HEX FLANGE HEAD CA	3	——
5	C3903210	NUT,HEXAGON FLANGE	1	——
6	C3919952	SCREW,HEX FLANGE HEAD	1	——
7	C3944312	BRACER，ALTERNATOR	1	——
——END——

SUPPORT,FRONT ENGINE
NO	Part NO	Part Name	QTY	REMARKS
1	C3093938	SCREW,HEX FLANGE HEAD CA	8	——
2	C3967811	SUPPORT,FRONT ENGINE	1	——
3	C3967812	SUPPORT,FRONT ENGINE	1	——
——END——

DEVICE,SIGNAL GENERATING
NO	Part NO	Part Name	QTY	REMARKS
1	C3967252	SENSOR,SPEED	1	——
——END——

DRIVE，FAN
NO	Part NO	Part Name	QTY	REMARKS
1	C3415603	SUPPORT,FAN	1	——
2	C3900634	SCREW,HEX FLANGE HEAD CA	4	——
3	C3926855	PULLEY，FAN	1	——
——END——

MOUNTING,FAN DRIVE
NO	Part NO	Part Name	QTY	REMARKS
1	C3903990	SCREW,HEX FLANGE HEAD	4	——
——END——

PLUMBING,AIR FUEL CONTR
NO	Part NO	Part Name	QTY	REMARKS
1	C3008465	PLUG,PIPE	2	——
2	C3282406	TEE，STREET PIPE	1	——
3	C3415336	CONNECTOR,MALE	2	——
4	C3415457	TUBE,AIR FUEL CONTROL	1	——
5	C3902425	SEALING WASHER	2	——
6	C3908110	PLUG,THREADED	2	——
7	C3909557	BUSHING，REDUCING PIPE	1	——
——END——

FILTER，FUEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3903293	NUT,HEX FLANGE	1	——
2	c3906694	SEAL，RECTANGLE	1	——
3	C3906695	SEAL，RECTANGLE	1	——
4	C3925955	ADAPTER,FILTER HEAD	1	——
5	C3930942	FILTER,FUEL	1	——
6	C3931063	FILTER,FUEL	1	——
7	C4934663	HEAD,FUEL FILTER	1	——
——END——

PLUMBING,FUEL FILTER
NO	Part NO	Part Name	QTY	REMARKS
1	C3863988	WASHER,SEALING	1	——
2	C3905860	SCREW,BANJO CONNECTOR	1	——
3	C3911446	SCREW,BANJO CONNECTOR	1	——
4	C3939570	Screw,Captive washer cap	1	——
5	C3918192	WASHER，SEALING	1	——
6	C3924725	SCREW,BANJO CONNECTOR	1	——
7	C3937342	TUBE，FUEL SUPPLY	1	——
8	C3963983	WASHER,SEALING	2	——
——END——

HOUSING,FLYWHEEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3008469	PLUG,PIPE	1	——
2	C3900629	SCREW,HEX FLANGE HEAD	2	——
3	C3908095	Plate,Cover	1	——
4	C3910248	PLUG,O RING	1	——
5	C3910260	SEAL,O RING	1	——
6	C3912473	SEAL,RECTANGULAR RING	1	——
7	C3920447	SCREW,HEX FLANGE HEAD CA	12	——
8	C3928989	CLIP	1	——
9	C3939353	GASKET,REAR COVER	1	——
10	C3974512	HOUSING,FLYWHEEL	1	——
11	C3991306	SCREW HEX FLANGE HEAD	8	——
12	C4943504	COVER,REAR	1	——
13	C3933384	COVER,REAR	1	——
14	C3968563	SEAL,OIL	1	——
——END——

PUMP,FUEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3969377	PUMP,FUEL INJECTION	1	——
——END——

COUPLING,FUEL PUMP
NO	Part NO	Part Name	QTY	REMARKS
1	C3282372	STUD	4	——
2	C3900589	NUT，HEXAGON FLANGE	1	——
3	C3901445	SCREW,HEX FLANGE HEAD CA	1	——
4	C3903464	SCREW，HEX FLANGE HEAD	1	——
5	C3903990	SCREW,HEX FLANGE HEAD	2	——
6	C3913366	SCREW,HEX FLANGE HEAD CA	2	——
7	C3920622	SCREW，HEX FLANGE HEAD	1	——
8	C3921357	BRACE，FUEL PUMP	1	——
9	C3926273	SUPPORT，FUEL PUMP	1	——
10	C3926722	SEAL，RECTANGULAR RING	1	——
11	C3926781	SUPPORT,FUEL PUMP	1	——
12	C3931380	GEAR,FUEL PUMP	1	——
13	C3938091	SUPPORT，FUEL PUMP	1	——
14	C3969698	SEAL,O RING	1	——
15	C4988581	NUT,HEXAGON FLANGE	4	——
——END——

PUMP,FUEL TRANSFER
NO	Part NO	Part Name	QTY	REMARKS
1	C3415661	PUMP,FUEL TRANSFER	1	——
2	C3909310	SCREW，HEX FLANGE HEAD	2	——
3	C3916361	SCREW,BANJO CONNECTOR	1	——
4	C3918539	TUBE，FUEL SUPPLY	1	——
5	C3939258	GASKET，COVER PLATE	1	——
6	C3963983	WASHER,SEALING	2	——
——END——

PLUMBING,FUEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3282059	CLIP	1	——
2	C3282141	SCREW,BANJO CONNECTOR	6	——
3	C3415562	TUBE,FUEL DRAIN	1	——
4	C3863988	WASHER,SEALING	2	——
5	C3900626	SCREW,HEX FLANGE HEAD CA	1	——
6	C3903380	SEAL,BANJO CONNECTOR	6	——
7	C3918188	WASHER，SEALING	2	——
8	C3922667	MANIFOLD，FUEL	1	——
9	C3924726	VALVE，CHECK	1	——
——END——

VALVE,FUEL SHUTOFF
NO	Part NO	Part Name	QTY	REMARKS
1	3910959	NUT,LOCK	1	——
2	C3919449	Pin,Cotter	1	——
3	C3925393	SOLATOR HEXAGONHEAD WTHF	2	——
4	C3936683	SCREW,HEX FLANGE HEAD CA	2	——
5	C3936684	SCREW,HEX FLANGE HEAD CA	2	——
6	C3936685	SCREW,HEX FLANGE HEAD CA	1	——
7	C4935573	SOLENOID,FUEL PUMP	1	——
8	C4935574	BRACKET,SOLENOID	1	——
9	C4937894	LEVER,SHUTOFF VAVLE	1	——
10	D3529610	WASHER,PLAIN	2	——
11	S 600	WASHER,LOCK	3	——
——END——

FLYWHEEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3960780	FLYWHEEL	1	——
——END——

MOUNTING,FLYWHEEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3900269	Washer,Plain	4	——
2	C3900269	Washer,Plain	4	——
3	C3977274	SCREW,HEXAGON HEAD CAP	4	——
4	C3977274	SCREW,HEXAGON HEAD CAP	4	——
——END——

MOUNTING，GEAR COVER
NO	Part NO	Part Name	QTY	REMARKS
1	C3925883	SCREW，HEX FLANGE HEAD	2	——
——END——

COVER,FRONT GEAR
NO	Part NO	Part Name	QTY	REMARKS
1	C3925883	SCREW，HEX FLANGE HEAD	13	——
2	C3926863	SCREW,HEX FLANGE HEAD CA	11	——
3	C3938077	NUT,LOCK	5	——
4	C3942535	SEAL，OIL	1	——
5	C3941786	CARRIER,SEAL	1	——
6	C3968562	SEAL,OIL	1	——
7	C3943813	COVER,GEAR	1	——
——END——

PLUMBING,CABIN HEATER
NO	Part NO	Part Name	QTY	REMARKS
1	C156075	PLUG,EXPANSION	2	——
2	C3008469	PLUG,PIPE	2	——
——END——

PUMP,AUXILIARY
NO	Part NO	Part Name	QTY	REMARKS
1	C154916	GASKET,HYDRAULIC PUMP	1	——
2	C3903464	SCREW，HEX FLANGE HEAD	2	——
3	C3967421	ELBOW,MALE ADAPTER	1	——
4	C3967429	PUMP,HYDRAULIC	1	——
——END——

CONNECTION,AIR INTAKE
NO	Part NO	Part Name	QTY	REMARKS
1	C3415610	GASKET，CONNECTION	1	——
2	C3900631	SCREW,HEX FLANGE HEAD	1	——
3	C3900633	SCREW,HEX FLANGE HEAD	7	——
4	C3960670	CONNECTION,AIR INTAKE	1	——
——END——

MANIFOLD,AIR INTAKE
NO	Part NO	Part Name	QTY	REMARKS
1	C3354397	COVER，INTAKE MANIFOLD	1	——
2	C3938036	SCREW，HEX FLANGE HEAD	11	——
3	D3936993	GASKET,INT MANIFOLD	1	——
——END——

CONNECTION，AIR TRANSFER
NO	Part NO	Part Name	QTY	REMARKS
1	C3008465	PLUG,PIPE	1	——
2	C3415547	CLAMP,V BAND	1	——
3	C3883284	SEAL,O RING	1	——
4	C3918327	PIPE,AIR TRANSFER	1	——
——END——

BRACKET，LIFTING
NO	Part NO	Part Name	QTY	REMARKS
1	C3901249	SCREW,HEX FLANGE HEAD	2	——
2	C3906440	BRACKET,LIFTING	1	——
3	C3907861	BRACKET,LIFTING	1	——
4	C4991876	SCREW,HEXAGON HEAD CAP	2	——
——END——

COOLER,ENGINE OIL
NO	Part NO	Part Name	QTY	REMARKS
1	C3918174	GASKET,OIL COOLER CORE	1	——
2	C3929011	GASKET,LUB OIL CLR COV	1	——
3	C3966976	SCREW,HEX FLANGE HEAD	11	——
4	C3974815	CORE,COOLER	1	——
5	C4936396	HEAD,LUB OIL FILTER	1	——
——END——

FILTERMLUBRICATING OIL
NO	Part NO	Part Name	QTY	REMARKS
1	C3401544	ELEMENT,LUB OIL FILTER	1	——
——END——

GAUGE,OIL LEVEL
NO	Part NO	Part Name	QTY	REMARKS
1	C3285703	TUBE,OIL GAUGE	1	——
2	C3943808	PLUG,EXPANSION	1	——
3	C3945613	DIPSTICK	1	——
4	C4935907	CLIP	1	——
——END——

OIL,ENGINE
NO	Part NO	Part Name	QTY	REMARKS
1	C4983154	TAG	1	——
2	C4983155	TAG	1	——
——END——

PUMP,LUBRICATING OIL
NO	Part NO	Part Name	QTY	REMARKS
1	C3900677	SCREW,HEXAGON HEAD CAP	4	——
2	C3966840	PUMP,LUBRICATING OIL	1	——
——END——

CONTROL,MNL TRT LEVER
NO	Part NO	Part Name	QTY	REMARKS
1	C3967109	WASHER,PLAIN	2	——
2	C3967110	WASHER,SPRING	2	——
3	C3967285	BRACE,ACCESSORY DRIVE	1	——
4	C3967286	SCREW,HEXAGON HEAD CAP	1	——
5	C3967287	WASHER,SPRING	1	——
6	C3967288	WASHER,PLAIN	1	——
7	C3975926	BRACKET,THROTTLE CONTROL	1	——
8	C4991519	NUT,REGULAR HEXAGON	2	——
——END——

ARRANGEMENT,OIL FILL
NO	Part NO	Part Name	QTY	REMARKS
1	C3900678	SCREW，HEX FLANGE HEAD	1	——
2	C3901895	CAP,FILLER	1	——
3	C3903475	SEAL，RECTANGLE	1	——
4	C3905401	PLUG,EXPANSION	1	——
5	C3914738	TUBE,OIL FILLER	1	——
6	C3921644	CONNECTION,OIL FILLER	1	——
7	C3936876	SEAL，RECTANGULAR RING	2	——
8	C62906 B	SPACER,MOUNTING	1	——
9	C68189	CLIP	1	——
——END——

PAN，OIL
NO	Part NO	Part Name	QTY	REMARKS
1	C3900628	SCREW,HEX FLANGE HEAD	2	——
2	C3901865	SCREW,HEX FLANGE HEAD CA	1	——
3	C3902425	SEALING WASHER	1	——
4	C3906216	NUT,HEXAGON FLANGE	1	——
5	C3910960	PLAIN WASHER	1	——
6	C3913638	SCREW,HEX FLANGE HEAD CA	2	——
7	C3914013	PAN,OIL	1	——
8	C3920400	SCREW,HEX FLANGE HEAD CA	32	——
9	C3920773	WASHER,SEALING	1	——
10	C3924147	PLUG，THREADED	1	——
11	C3924148	PLUG，THREADED	1	——
12	C3926865	SPACER,MOUNTING	2	——
13	C3927611	BRACE,TUBE	1	——
14	C3928828	CONNECTION，OIL SUCTIO	1	——
15	C3939352	GASKET,OIL SUC CONNECT	1	——
16	C3973509	GASKET,OIL PAN	1	——
——END——

PULLEY,ACCESSORY
NO	Part NO	Part Name	QTY	REMARKS
1	C3919624	PULLEY,ACCESSORY DRIVE	1	——
——END——

PARTS,PERFORMANCE
NO	Part NO	Part Name	QTY	REMARKS
1	C3008464	PLUG,PIPE	1	——
2	C3008466	PLUG,PIPE	1	——
3	C3008468	PLUG,PIPE	1	——
4	C3415501	GASKET,CYLINDER HEAD	1	——
5	C3900227	SCREW,HEXGON HEAD CAP	2	——
6	C3901383	ROD，ENGINE CONNECTING	6	——
7	C3902332	KEY,PLAIN WOODRUFF	1	——
8	C3902425	SEALING WASHER	2	——
9	C3909886	SEAL，INJECTOR	6	——
10	C3910279	CLAMP,INJECTOR	6	——
11	C3917729	SCREW，HEX FLANGE HEAD	12	——
12	C3918777	GEAR，CAMSHAFT	1	——
13	C3919918	RING,COMPRESSION PISTO	6	——
14	C3920692	RING,RETAINING	12	——
15	C3921919	RING,OIL PISTON	6	——
16	C3922686	RING,COMPRESSION PISTO	6	——
17	C3923478	CAMSHAFT	1	——
18	C3924148	PLUG，THREADED	2	——
19	C3925878	PISTON,ENGINE	6	——
20	C3927155	SUPPORT,CAMSHAFT THRUST	1	——
21	C3928384	INJECTOR	6	——
22	C3934046	PIN,PISTON	6	——
23	C3950661	BEARING,CONNECTING ROD	12	——
24	C3960043	SCREW,HEX FLANGE HEAD	14	——
25	C4938632	HEAD,CYLINDER	1	——
26	3901177	COLLET,VALVE	24	——
27	C3912976	RETAINER,VALVE SPRING	12	——
28	C3916588	SPRING,VALVE	6	——
29	C3921444	VALVE ，EXHAUST	6	——
30	C3924492	VALVE,INTAKE	6	——
31	C3927642	SEAL,VALVE STEM	12	——
32	C3973493	HEAD,CYLINDER	1	——
33	3908830	INSERT,VALVE	6	——
34	3925863	GUIDE,VALVE STEM	12	——
35	3970278	INSERT,VALVE	6	——
36	C3914035	PLUG,EXPANSION	5	——
37	C3920443	PLUG,EXPANSION	1	——
38	C3922072	PLUG,EXPANSION	2	——
39	C3991085	SPRING，VALVE	6	——
40	C4991526	SCREW,HEX FLANGE HEAD CA	6	——
——END——

PLUMBING,CY HEAD COOLANT
NO	Part NO	Part Name	QTY	REMARKS
1	C3008464	PLUG,PIPE	1	——
2	C3912900	PLUG ,EXPANSION	1	——
——END——

PLUMBING,INJECTOR
NO	Part NO	Part Name	QTY	REMARKS
1	C3925324	TUBE，INJECTOR FUEL	1	——
2	C3966996	TUBE,INJECTOR FUEL SUPPL	1	——
——END——

TURBOCHARGER
NO	Part NO	Part Name	QTY	REMARKS
1	C3755843	GASKET,TURBOCHARGER	1	——
2	C3818823	STUD	4	——
3	C3818824	NUT,HEXAGON FLANGE	4	——
4	C4051343	TURBOCHARGER	1	——
——END——

LEVER，ROCKER
NO	Part NO	Part Name	QTY	REMARKS
1	C3905194	ROD，PUSH	12	——
2	C3919677	MANIFOLD，OIL	1	——
3	C3934921	LEVER,ROCKER	6	——
——END——

VENT,ENGINE COOLANT
NO	Part NO	Part Name	QTY	REMARKS
1	C3970002	COUPLING,PLAIN HOSE	1	——
2	C4944603	ELBOW,PLAIN STREET PIPE	1	——
——END——

SWITCH,OIL PRESSURE
NO	Part NO	Part Name	QTY	REMARKS
1	C3968300	SWITCH,PRESSURE	1	——
——END——

SWITCH,COO TEMPERATURE
NO	Part NO	Part Name	QTY	REMARKS
1	C3979176	SENSOR,TEMPERATURE	1	——
——END——

MOUNTING，STARTING
NO	Part NO	Part Name	QTY	REMARKS
1	C3968466	SCREW,TWELVE POINT	3	——
——END——

PAINT
NO	Part NO	Part Name	QTY	REMARKS
1	C3991084	NAMEPLATE	1	——
——END——

MOTOR,STARTING
NO	Part NO	Part Name	QTY	REMARKS
1	C3415537	MOTOR,STARTING	1	——
——END——

ARRANGEMENT,TURBOCHARGER
NO	Part NO	Part Name	QTY	REMARKS
1	C3914708	LOCKPLATE	12	——
2	C3929537	SCREW,HEX HEAD CAP	12	——
3	C3929779	MANIFOLD,EXHAUST	1	——
4	C3932063	GASKET,EXHAUST	6	——
5	C4942381	DECAL	1	——
——END——

COOLER，TOR CONVERTER
NO	Part NO	Part Name	QTY	REMARKS
1	C3089238	PLUG，THREADED	2	——
2	C3089239	PLUG，THREADED	1	——
3	C3089240	SEAL ，O RING	1	——
4	TO L006	TOOL,SERVICE	1	——
5	C4996943	TOOL,SERVICE	1	——
6	C4996951	BAG,SERVICE TOOL	1	——
——END——

PLUMBING,TURBOCHARGER
NO	Part NO	Part Name	QTY	REMARKS
1	C3285747	GASKET，OIL DRAIN	1	——
2	C3415317	HOSE,FLEXIBLE	1	——
3	C3415347	CONNECTOR,FEMALE	2	——
4	C3037236	SEAL,O RING	1	——
5	C3415328	CONNECTOR,FEMALE	1	——
6	C3900589	NUT，HEXAGON FLANGE	1	——
7	C3900630	Screw,Hex flange headcap	2	——
8	C3920706	PLUG,EXPANSION	1	——
9	C3924389	WASHER,SEALING	2	——
10	C3927317	COUPLING,ELBOW HOSE	1	——
11	C3928629	CONNECTION，TUR OIL	1	——
12	C3926842	CONNECTION，TUBE OIL	1	——
13	C3928624	SEAL，O RING	2	——
14	C3975963	HOSE,ELBOW	1	——
15	C3975964	TUBE,AIR FUEL CONTROL	1	——
16	C3991043	HOSE,PLAIN	1	——
17	D3914420	CLAMP,HOSE	2	——
18	D3920719	CLAMP,HOSE	2	——
——END——

COVER，VALVE
NO	Part NO	Part Name	QTY	REMARKS
1	C3902466	SEAL，RECTANGLE	1	——
2	c3902468	CAP,FILLER	1	——
3	C3905449	SEAL,ROCKER LEVER COVER	1	——
4	C3910824	SEAL,O RING	6	——
5	C3922639	SCREW,HEX HEAD CAP	6	——
6	C3930903	COVER，VALVE	1	——
——END——

LOCATION,CRN RESISTOR
NO	Part NO	Part Name	QTY	REMARKS
1	C179901	VALVE，SHUTOFF	2	——
2	C179903	COUPLING，ELBOW HOSE	2	——
3	C3008469	PLUG,PIPE	2	——
4	C3415608	BUSHING,REDUCING PIPE	2	——
5	C3415680	HEAD,CORROSION RESISTOR	1	——
6	C3903112	SCREW,HEX FLANGE HEAD CA	4	——
7	C3910509	CLAMP，HOSE	4	——
8	C3966481	SUPPORT,FILTER	1	——
9	C3973898	DECAL	1	——
10	C3975596	HOSE,PLAIN	1	——
11	C3975597	HOSE,PLAIN	1	——
12	C4058964	RESISTOR,CORROSION	1	——
——END——

CONNECTION，WATER INLE
NO	Part NO	Part Name	QTY	REMARKS
1	C3415658	GASKET,CONNECTION	1	——
2	C3900630	Screw,Hex flange headcap	2	——
3	C3944720	CONNECTOR，WATER INLET	1	——
——END——

CONNECTION，WATER OUTL
NO	Part NO	Part Name	QTY	REMARKS
1	C3900631	SCREW,HEX FLANGE HEAD	2	——
2	C3944429	CONNECTOR，WATER OUTLE	1	——
——END——

TENSIONER，BELT
NO	Part NO	Part Name	QTY	REMARKS
1	C3282433	SCREW，HEX FLANGE HEAD	1	——
2	C3976831	TENSIONER,BELT	1	——
——END——

PUMP,WATER
NO	Part NO	Part Name	QTY	REMARKS
1	C3093730	SCREW，HEX FLANGE HEAD	3	——
2	C3940386	SEAL，O RING	1	——
3	C3966841	PUMP,WATER	1	——
——END——

PULLEY，WATER PUMP DRI
NO	Part NO	Part Name	QTY	REMARKS
1	C3911620	BELT,V RIBBED	1	——
——END——

CONNECTOR，TURBOCHARGE
NO	Part NO	Part Name	QTY	REMARKS
1	C3415546	CLAMP,V BAND	1	Random Items
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

DCEC C230-20 automotive engine is a 6-cylinders in line, 8.3 liter four-strokes engine with 114 mm bore and 135 mm stroke, equipped with PW2000 pump and RQV-K governor. DCEC C230-20 automotive engine comes with turbocharger and Air-Air intercooler, with a EURO II post-processor.

The prime power at 2200 RPM of DCEC C230-20 automotive engine is 230 HP.

As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system.

We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of C230-20 Automotive Engine

More fuel-efficient: Originated from the United States Cummins advanced design and superior manufacture, adapt to the demand of China’s economical improvement, make oil consumption lower 20 % than domestic products.
Super power, Low speed power overall upgrade, better starting performance, speed up faster, stronger climbing performance.
Excellent reliability, Key parts design reserved fully surplus, strength is over 30 % more than the similar engine, engine life is longer.
Lower maintenance and repair costs, Lower maintenance and repair costs, fewer parts quantity and lower use fault Make the engine comprehensive maintenance cost greatly reduced and maintenance time than similar type save 50 %.
Excellent cold start performance, equipped with air suction electric preheater and 7.8 kw power starter, completely improve the cold start performance of the engine. Through the arctic village-MoHe of China – 36 °C extreme low temperature validation.

Technical Specifications
