6BT5.9-G2-A G-Drive Engine Parts
For the same model of engine, Cummins havedifferent SO (Shop Order) number, which have some tiny different to match therequirement from different customers, but most of the major components are thesame in the same model, so we randomly choose one of the SO number parts listto show on our website for your reference, if you need accurate parts list,please contact PartMac with your engine name plate, engine serial number orengine SO number, then our sales team will go back to you with parts catalogmatching to your engine. We provide maintenance manual, operation manual aswell technical support, we can also provide on-site engineer services to do therepair and maintenance works if customers pay all the relevant costs, pleasefeel free to contact us if you have any other questions.
Technical Specifications
| Engine Model: | 6BT5.9-G2-A(-A means 1500 RPM engine) |
| Engine Type: | 6 Cylinders |
| Displacement: | 5.9 L |
| Rated Speed: | 1500 RPM |
| Rated Power / Speed: | 96 kW @ 1500 RPM |
| Fuel System: | Beiyou PB Pump /GAC 24V/12V Electronic Governor Beiyou PB Pump/Fuchuang Electronic Governor |
| Cooling System: | 54 kW |
| Aspiration Method: | Turbocharged |
| Emission Standard: | N/A |
| Bore*Storke: | 102 mm * 120 mm |
| Packing Size(L*W*H): | 1080 mm * 625 mm * 1085 mm |
| Wet Weight: | 432 kg |
| Lead Time: | 15-30 Working Days |
| Payment Terms: | T/T ,L/C |
Click Kit Name to Check Part List
- Air Cleaner
- Air Intake Heater
- Agency Approval
- Cylinder Block
- Front Gear Cover
- Base Parts
- Rocker Lever
- Cam Follower
- Cam Follower Cover Arrangement
- Vibration Damper
- Front Gear Train Accessory Drive
- Drain Location
- Electrical Accessories
- Thermostat
- Alternator
- Alternator Mounting
- Alternator Drive
- Tachometer Drive
- Mechanical Tachometer Drive
- Front Engine Support
- Coolant Temperature Sensor
- Speed Sensor
- Oil Pressure Sensor
- Fan Drive
- Air Fuel Control Plumbing
- Fuel Filter Plumbing
- Fuel Filter
- Flywheel Housing
- Engine Fan
- Fuel Pump Coupling
- Fuel Pump
- Fuel Pump Support
- Fuel Rating
- Fuel System Accessories
- Fuel Transfer Pump
- Fuel Plumbing
- Fuel Shutoff Valve
- Flywheel
- Lifting Bracket
- Engine Labeling
- Engine Oil Cooler
- Oil Level Gauge
- Lubricating Oil Pump
- Literature
- Cylinder Block Cover
- Oil Pan
- Oil Pan
- Oil Pan Mounting
- Performance Parts
- Cylinder Head Mounting
- Cylinder Head
- Turbocharger
- Rear Engine Support
- Electric Starting Accessories
- Starting Motor Mounting
- Fan Pilot Spacer
- Paint
- Engine Installation Kit
- Shipping Arrangement
- Starting Motor
- Turbocharger Arrangement
- Air Intake Manifold
- Air Crossover Connection
- Air Crossover Connection
- Exhaust Manifold Mounting
- Exhaust Manifold
- Thermostat Housing
- Service Tool
- Turbocharger Plumbing
- Valve Cover
- Engine Coolant Vent
- Water Inlet Connection
- Water Inlet Connection
- Water Pump
- Exhaust Outlet Connection
Air Cleaner | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | AC9276 | Air Cleaner | — | — |
| 2 | 140311 | T BOLT CLAMP | 1 | — |
| 3 | 208326 | T BOLT CLAMP | 1 | — |
| 4 | 3281239 | AIR CLEANER CAP | 1 | — |
| 5 | 3415548 | T BOLT CLAMP | 1 | — |
| 6 | 3900589 | HEXAGON FLANGE NUT | 4 | — |
| 7 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 8 | 3900637 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 9 | 5257098 | AIR CLEANER BRACKET | 1 | — |
| 10 | 5257102 | AIR CLEANER | 1 | — |
| 11 | 5257103 | MOLDED HOSE | 1 | — |
| ——END—— | ||||
Air Intake Heater | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | AH9000 | Air Intake Heater | 1 | — |
| 2 | — | SCREW,STUDDED FLANGE CAP | — | — |
| 3 | — | RETAINER,COVER | — | — |
| 4 | — | AID,STARTING | — | — |
| ——END—— | ||||
Agency Approval | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | AP90248 | Agency Approval | — | — |
| 2 | — | APPROVAL,AGENCY | — | — |
| ——END—— | ||||
Cylinder Block | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | BP9072 | Cylinder Block | — | — |
| 2 | 3008468 | PIPE PLUG | 1 | — |
| 3 | 3900068 | RING DOWEL | 2 | — |
| 4 | 3900257 | PIN DOWEL | 2 | — |
| 5 | 3900687 | EXPANSION PLUG | 1 | — |
| 6 | 3902343 | RING DOWEL | 2 | — |
| 7 | 3906619 | PIPE PLUG | 2 | — |
| 8 | 3928797 | CYLINDER BLOCK | 1 | — |
| 9 | 3937214 | PISTON COOLING NOZZLE | 6 | — |
| 10 | 3978818 | MAIN BEARING | 6 | — |
| 11 | 3978820 | MAIN BEARING | 7 | — |
| 12 | 3978822 | CRANKSHAFT THRUST BEARING | 1 | — |
| ——END—— | ||||
Front Gear Cover | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | BP9122 | Front Gear Cover | — | — |
| 2 | 3900633 | HEXAGON FLANGE HEAD CAP SCREW | 11 | — |
| 3 | 3907998 | ROUND HEAD CAP SCREW | 2 | — |
| 4 | 3913995 | TIMING HOUSING | 1 | — |
| 5 | 3915772 | RECTANGULAR RING SEAL | 1 | — |
| 6 | 3924962 | HEXAGON FLANGE HEAD CAP SCREW | 16 | — |
| 7 | 3938156 | GEAR HOUSING GASKET | 1 | — |
| 8 | 4991493 | GEAR COVER | 1 | — |
| 9 | 5267782 | GEAR HOUSING | 1 | — |
| ——END—— | ||||
Base Parts | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | BP9126 | Base Parts | — | — |
| 2 | — | BLOCK,CYLINDER | — | — |
| 3 | — | CRANKSHAFT,ENGINE | — | — |
| 4 | — | HOUSING,REAR GEAR | — | — |
| ——END—— | ||||
Rocker Lever | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | BP9710 | Rocker Lever | — | — |
| 2 | 3284377 | PUSH ROD | 12 | — |
| 3 | 3901221 | HEXAGON HEAD CAP SCREW | 6 | — |
| 4 | 3920781 | HEXAGON FLANGE HEAD CAP SCREW | 6 | — |
| 5 | 3934920 | ROCKER LEVER SUPPORT | 6 | — |
| ——END—— | ||||
Cam Follower | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | BP9711 | Cam Follower | — | — |
| 2 | — | BLOCK,CYLINDER | — | — |
| 3 | — | CRANKSHAFT,ENGINE | — | — |
| 4 | — | HOUSING,REAR GEAR | — | — |
| ——END—— | ||||
Cam Follower Cover Arrangement | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | CM9016 | Cam Follower Cover Arrangement | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 3 | 3918614 | PLAIN HOSE | 1 | — |
| 4 | 3990730 | PUSH ROD COVER | 1 | — |
| 5 | 4928971 | T BOLT CLAMP | 1 | — |
| 6 | 4994848 | GROMMET SEAL | 4 | — |
| 7 | 5316611 | COVER PLATE GASKET | 1 | — |
| ——END—— | ||||
Vibration Damper | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | DA9208 | Vibration Damper | — | — |
| 2 | 3903857 | HEXAGON FLANGE HEAD CAP SCREW | — | — |
| 3 | 3958258 | TUNED VIBRATION DAMPER | — | — |
| 4 | 5265057 | CRANKSHAFT FLANGE | — | — |
| ——END—— | ||||
Front Gear Train Accessory Drive | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | DF9051 | Front Gear Train Accessory Drive | — | — |
| 2 | 3901249 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3929751 | ACCESSORY DRIVE COVER GASKET | 1 | — |
| ——END—— | ||||
Drain Location | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | — | WASHER,SEALING | — | — |
| 2 | — | SCREW,BANJO CONNECTOR | — | — |
| 3 | — | HOSE,FLEXIBLE | — | — |
| 4 | — | MANIFOLD,FUEL | — | — |
| 5 | — | SCREW,TWELVE POINT CAP | — | — |
| 6 | — | HOSE,FLEXIBLE | — | — |
| 7 | — | HOSE,FLEXIBLE | — | — |
| 8 | — | UNION,MALE | — | — |
| 9 | — | SEAL,O RING | — | — |
| 10 | — | SCREW,BANJO CONNECTOR | — | — |
| 11 | — | WASHER,SEALING | — | — |
| 12 | — | SCREW,BANJO CONNECTOR | — | — |
| 13 | — | TUBE,FUEL DRAIN | — | — |
| 14 | — | TUBE,FUEL DRAIN | — | — |
| 15 | — | TUBE,FUEL DRAIN | — | — |
| 16 | — | TUBE,FUEL DRAIN | — | — |
| 17 | — | TUBE,FUEL DRAIN | — | — |
| 18 | — | TUBE,FUEL DRAIN | — | — |
| 19 | — | WASHER,SEALING | — | — |
| ——END—— | ||||
Electrical Accessories | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EA9118 | Electrical Accessories | — | — |
| 2 | 3901249 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 3 | 4932506 | GROUND WIRE | 1 | — |
| ——END—— | ||||
Thermostat | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EC9052 | Thermostat | — | — |
| 2 | 4930315 | Thermostat | 1 | — |
| ——END—— | ||||
Alternator | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EE9314 | Alternator | — | — |
| 2 | — | Alternator | — | — |
| ——END—— | ||||
Alternator Mounting | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EH97541 | Alternator Mounting | — | — |
| 2 | 3900631 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 3 | 3901249 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 4 | 3903105 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 5 | 3903210 | HEXAGON FLANGE NUT | 1 | — |
| 6 | 5309105 | ALTERNATOR SUPPORT | 1 | — |
| 7 | 5309106 | ALTERNATOR BRACE | 1 | — |
| ——END—— | ||||
Alternator Drive | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EH97545 | Alternator Drive | — | — |
| 2 | 3285958 | BELT TENSIONER BRACKET | 1 | — |
| 3 | 3288790 | V RIBBED BELT | 1 | — |
| 4 | 3900631 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 5 | 3925186 | FLAT HEAD CAP SCREW | 1 | — |
| 6 | 3937553 | BELT TENSIONER | 1 | — |
| 7 | 3967107 | PLAIN WASHER | 1 | — |
| 8 | 3979347 | HEXAGON HEAD CAP SCREW | 1 | — |
| ——END—— | ||||
Tachometer Drive | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EI9000 | Tachometer Drive | — | — |
| 2 | — | MODULE,RTE PRR MANAGER | — | — |
| ——END—— | ||||
Mechanical Tachometer Drive | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EI9701 | Mechanical Tachometer Drive | — | — |
| 2 | 3903463 | ACCESS HOLE COVER | 1 | — |
| 3 | 3903475 | RECTANGULAR RING SEAL | 1 | — |
| ——END—— | ||||
Front Engine Support | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EM9311 | Front Engine Support | — | — |
| 2 | 3335006 | HEXAGON HEAD CAP SCREW | 6 | — |
| 3 | 3967119 | SPRING WASHER | 6 | — |
| 4 | 4928962 | PLAIN WASHER | 6 | — |
| 5 | 4988361 | FRONT ENGINE SUPPORT | 1 | — |
| 6 | 4988362 | FRONT ENGINE SUPPORT | 1 | — |
| ——END—— | ||||
Coolant Temperature Sensor | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EO9106 | Coolant Temperature Sensor | — | — |
| 2 | 3967250 | TEMPERATURE SENSOR | 1 | — |
| ——END—— | ||||
Speed Sensor | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EO9156 | Speed Sensor | — | — |
| 2 | — | SENSOR,ENGINE SPEED | — | — |
| ——END—— | ||||
Oil Pressure Sensor | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | EO9231 | Oil Pressure Sensor | — | — |
| 2 | 5368310 | PRESSURE SENSOR | 1 | — |
| ——END—— | ||||
Fan Drive | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FA9514 | Fan Drive | — | — |
| 2 | 3900678 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 3 | 3914458 | FAN PULLEY | 1 | — |
| 4 | 4932907 | FAN SUPPORT | 1 | — |
| ——END—— | ||||
Air Fuel Control Plumbing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FE9081 | Air Fuel Control Plumbing | — | — |
| 2 | 3906619 | PIPE PLUG | 1 | — |
| ——END—— | ||||
Fuel Filter Plumbing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FF90104 | Fuel Filter Plumbing | — | — |
| 2 | 3960421 | FUEL SUPPLY TUBE | 1 | — |
| 3 | 3960692 | HOSE CLAMP | 1 | — |
| ——END—— | ||||
Fuel Filter | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FF90117 | Fuel Filter | — | — |
| 2 | 3905860 | BANJO CONNECTOR SCREW | 1 | — |
| 3 | 3906695 | RECTANGULAR RING SEAL | 1 | — |
| 4 | 3925955 | FILTER HEAD ADAPTER | 1 | — |
| 5 | 3930942 | FUEL FILTER | 1 | — |
| 6 | 3931063 | FUEL FILTER | 1 | — |
| 7 | 3963983 | SEALING WASHER | 2 | — |
| 8 | 4928959 | REGULAR HEXAGON NUT | 1 | — |
| 9 | 4980085 | RECTANGULAR RING SEAL | 1 | — |
| 10 | 4989118 | FUEL FILTER HEAD | 1 | — |
| 11 | 4991525 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| ——END—— | ||||
Flywheel Housing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FH9634 | Flywheel Housing | — | — |
| 2 | 3008469 | PIPE PLUG | 1 | — |
| 3 | 3900225 | HEXAGON HEAD CAP SCREW | 2 | — |
| 4 | 3900627 | HEXAGON FLANGE HEAD CAP SCREW | 6 | — |
| 5 | 3908095 | COVER PLATE | 1 | — |
| 6 | 3910248 | O RING PLUG | 1 | — |
| 7 | 3910260 | O RING SEAL | 1 | — |
| 8 | 3910540 | HEXAGON FLANGE HEAD CAP SCREW | 8 | — |
| 9 | 3912473 | O RING SEAL | 1 | — |
| 10 | 3928989 | CLIP | 1 | — |
| 11 | 4947579 | FLYWHEEL HOUSING | 1 | — |
| 12 | 4947667 | REAR COVER GASKET | 1 | — |
| 13 | 5266601 | REAR COVER | 1 | — |
| ——END—— | ||||
Engine Fan | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FN9184 | Engine Fan | — | — |
| 2 | 4931786 | Engine Fan | 1 | — |
| ——END—— | ||||
Fuel Pump Coupling | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FP91307 | Fuel Pump Coupling | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 3 | 3937123 | STUD | 4 | — |
| 4 | 3960485 | FUEL PUMP GEAR | 1 | — |
| 5 | 3967107 | PLAIN WASHER | 2 | — |
| 6 | 3967108 | SPRING WASHER | 2 | — |
| 7 | 3977319 | MALE CONNECTOR | 1 | — |
| 8 | 3977322 | FLEXIBLE HOSE | 1 | — |
| 9 | 4988581 | HEXAGON FLANGE NUT | 4 | — |
| 10 | 4991523 | HEXAGON HEAD CAP SCREW | 2 | — |
| 11 | 4991548 | FUEL PUMP BRACE | 1 | — |
| 12 | 4991549 | FUEL PUMP SUPPORT | 1 | — |
| ——END—— | ||||
Fuel Pump | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FP91902 | Fuel Pump | — | — |
| 2 | 5262671 | Fuel Pump | 1 | — |
| ——END—— | ||||
Fuel Pump Support | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FP92090 | Fuel Pump Support | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| ——END—— | ||||
Fuel Rating | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FR93146 | Fuel Rating | — | — |
| ——END—— | ||||
Fuel System Accessories | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FS90233 | Fuel System Accessories | — | — |
| 2 | 3963988 | SEALING WASHER | 2 | — |
| 3 | 5334643 | BANJO CONNECTOR | 1 | — |
| 4 | 5334647 | BANJO CONNECTOR SCREW | 1 | — |
| ——END—— | ||||
Fuel Transfer Pump | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FS90239 | Fuel Transfer Pump | — | — |
| 2 | 3900631 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3914284 | MOUNTING SPACER | 1 | — |
| 4 | 3916361 | BANJO CONNECTOR SCREW | 1 | — |
| 5 | 3939258 | COVER PLATE GASKET | 2 | — |
| 6 | 3963983 | SEALING WASHER | 2 | — |
| 7 | 4940671 | FUEL SUPPLY TUBE | 1 | — |
| 8 | 5334912 | FUEL TRANSFER PUMP | 1 | — |
| ——END—— | ||||
Fuel Plumbing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FT9318 | Fuel Plumbing | — | — |
| 2 | 3905307 | BANJO CONNECTOR SCREW | 6 | — |
| 3 | 3918188 | SEALING WASHER | 2 | — |
| 4 | 3924726 | CHECK VALVE | 1 | — |
| 5 | 3967129 | BANJO CONNECTOR | 1 | — |
| 6 | 4928975 | CLIP | 1 | — |
| 7 | 4931027 | FUEL MANIFOLD | 1 | — |
| 8 | 4931179 | TUBE BRACE | 1 | — |
| 9 | 4991513 | HEXAGON HEAD CAP SCREW | 1 | — |
| 10 | 5289747 | BANJO CONNECTOR SEAL | 6 | — |
| 11 | 5297709 | INJECTOR FUEL SUPPLY TUBE | 1 | — |
| 12 | 5341097 | INJECTOR FUEL SUPPLY TUBE | 1 | — |
| ——END—— | ||||
Fuel Shutoff Valve | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FV9002 | Fuel Shutoff Valve | — | — |
| 2 | — | VALVE,FUEL SHUTOFF | — | — |
| ——END—— | ||||
Flywheel | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | FW90104 | Flywheel | — | — |
| 2 | 4939064 | FLYWHEEL | 1 | — |
| 3 | 4942710 | CAPTIVE WASHER CAP SCREW | 8 | — |
| ——END—— | ||||
Lifting Bracket | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LA9007 | Lifting Bracket | — | — |
| 2 | 3908118 | Lifting Bracket | 1 | — |
| 3 | 3910495 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| ——END—— | ||||
Engine Labeling | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LB9101 | Engine Labeling | — | — |
| 2 | 4983154 | TAG | 1 | — |
| 3 | 5291163 | IDENTIFICATION TAG | 2 | — |
| 4 | 5304240 | PROTECTIVE COVER | 1 | — |
| ——END—— | ||||
Engine Oil Cooler | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LC9020 | Engine Oil Cooler | — | — |
| 2 | 3900632 | HEXAGON FLANGE HEAD CAP SCREW | 14 | — |
| 3 | 3906619 | PIPE PLUG | 1 | — |
| 4 | 3937743 | LUBRICATING OIL FILTER CARTRIDGE | 1 | — |
| 5 | 3942915 | FILTER HEAD GASKET | 1 | — |
| 6 | 3957544 | COOLER CORE | 1 | — |
| 7 | 4934217 | LUBRICATING OIL FILTER HEAD | 1 | — |
| 8 | 5266445 | OIL COOLER CORE GASKET | 1 | — |
| ——END—— | ||||
Oil Level Gauge | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LG90442 | Oil Level Gauge | — | — |
| 2 | 3900955 | EXPANSION PLUG | 2 | — |
| 3 | 4941539 | DIPSTICK | 1 | — |
| ——END—— | ||||
Lubricating Oil Pump | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LP9064 | Lubricating Oil Pump | — | — |
| 2 | 3900677 | HEXAGON HEAD CAP SCREW | 4 | — |
| 3 | 5346430 | LUBRICATING OIL PUMP | 1 | — |
| ——END—— | ||||
Literature | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | LT9001 | Literature | — | — |
| ——END—— | ||||
Cylinder Block Cover | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | OB9005 | Cylinder Block Cover | — | — |
| 2 | 3901249 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3906696 | RECTANGULAR RING SEAL | 1 | — |
| 4 | 4938410 | OIL FILLER TUBE | 1 | — |
| ——END—— | ||||
Oil Pan | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | OP9005 | Oil Pan | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3915703 | OIL PAN | 1 | — |
| 4 | 3921992 | OIL SUCTION CONNECTION | 1 | — |
| 5 | 3938157 | FLANGE GASKET | 1 | — |
| 6 | 3973071 | THREADED PLUG | 1 | — |
| 7 | 4992508 | THREADED PLUG | 1 | — |
| ——END—— | ||||
Oil Pan | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | OP9006 | Oil Pan | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3915703 | OIL PAN | 1 | — |
| 4 | 3921992 | OIL SUCTION CONNECTION | 1 | — |
| 5 | 3938157 | FLANGE GASKET | 1 | — |
| 6 | 3973071 | THREADED PLUG | 1 | — |
| 7 | 4992508 | THREADED PLUG | 1 | — |
| ——END—— | ||||
Oil Pan Mounting | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | OP9702 | Oil Pan Mounting | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3920400 | HEXAGON FLANGE HEAD CAP SCREW | 36 | — |
| 4 | 3959052 | OIL PAN GASKET | 1 | — |
| ——END—— | ||||
Performance Parts | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | PP43076 | Performance Parts | — | — |
| 2 | 3355015 | INJECTOR | 6 | — |
| 3 | 3900227 | HEXAGON HEAD CAP SCREW | 2 | — |
| 4 | 3902332 | PLAIN WOODRUFF KEY | 1 | — |
| 5 | 3904531 | COMPRESSION PISTON RING | 6 | — |
| 6 | 3909356 | RECTANGULAR RING SEAL | 6 | — |
| 7 | 3918315 | COMPRESSION PISTON RING | 6 | — |
| 8 | 3920691 | RETAINING RING | 12 | — |
| 9 | 3927155 | CAMSHAFT THRUST SUPPORT | 1 | — |
| 10 | 3929028 | CAMSHAFT GEAR | 1 | — |
| 11 | 3932520 | OIL PISTON RING | 6 | — |
| 12 | 3969562 | CONNECTING ROD (STUD) BEARING | 6 | — |
| 13 | 3970366 | CAMSHAFT | 1 | — |
| 14 | 4893693 | CONNECTING ROD BEARING | 6 | — |
| 15 | 4943979 | ENGINE CONNECTING ROD | 6 | — |
| 16 | 4991277 | ENGINE PISTON | 6 | — |
| ——END—— | ||||
Cylinder Head Mounting | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | PP97298 | Cylinder Head Mounting | — | — |
| 2 | — | PLUMBING,INJECTOR | — | — |
| 3 | — | INJECTOR | — | — |
| 4 | — | HEAD,CYLINDER | — | — |
| 5 | — | TURBOCHARGER | — | — |
| 6 | — | ROD,PISTON AND CONNECTING | — | — |
| 7 | — | CAMSHAFT | — | — |
| ——END—— | ||||
Cylinder Head | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | PP98727 | Cylinder Head | — | — |
| 2 | 3008465 | PIPE PLUG | 2 | — |
| 3 | 3008468 | PIPE PLUG | 5 | — |
| 4 | 3008469 | PIPE PLUG | 1 | — |
| 5 | 3900250 | VALVE COLLET | 24 | — |
| 6 | 3916691 | VALVE SPRING | 6 | — |
| 7 | 3920779 | HEXAGON FLANGE HEAD CAP SCREW | 6 | — |
| 8 | 3920780 | HEXAGON FLANGE HEAD CAP SCREW | 14 | — |
| 9 | 3926700 | VALVE SPRING | 6 | — |
| 10 | 3957912 | VALVE STEM SEAL | 12 | — |
| 11 | 3957913 | VALVE SPRING RETAINER | 12 | — |
| 12 | 3966452 | CYLINDER HEAD | 1 | — |
| 13 | 4994143 | EXHAUST VALVE | 6 | — |
| ——END—— | ||||
Turbocharger | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | PP99442 | Turbocharger | — | — |
| 2 | 3818823 | STUD | 4 | — |
| 3 | 3818824 | REGULAR HEXAGON NUT | 4 | — |
| 4 | 3919369 | TURBOCHARGER GASKET | 1 | — |
| 5 | 3960404 | TURBOCHARGER | 1 | — |
| ——END—— | ||||
Rear Engine Support | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | RE9055 | Rear Engine Support | — | — |
| 2 | 3335006 | HEXAGON HEAD CAP SCREW | 8 | — |
| 3 | 3967119 | SPRING WASHER | 8 | — |
| ——END—— | ||||
Electric Starting Accessories | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SB9104 | Electric Starting Accessories | — | — |
| 2 | 3967109 | PLAIN WASHER | 4 | — |
| 3 | 3967110 | SPRING WASHER | 4 | — |
| 4 | 4988354 | RELAY | 2 | — |
| 5 | 4988412 | RELAY BRACKET | 1 | — |
| 6 | 4991519 | REGULAR HEXAGON NUT | 4 | — |
| 7 | 4991520 | HEXAGON HEAD CAP SCREW | 4 | — |
| ——END—— | ||||
Starting Motor Mounting | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SM9702 | Starting Motor Mounting | — | — |
| 2 | — | SCREW,TWELVE POINT CAP | — | — |
| ——END—— | ||||
Fan Pilot Spacer | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SP9110 | Fan Pilot Spacer | — | — |
| 2 | 3925344 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 3 | 4903110 | HEXAGON FLANGE HEAD CAP SCREW | 4 | — |
| 4 | 4931791 | FAN SUPPORT ADAPTER | 1 | — |
| 5 | 4988581 | HEXAGON FLANGE NUT | 4 | — |
| ——END—— | ||||
Paint | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SS9148 | Paint | — | — |
| ——END—— | ||||
Engine Installation Kit | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SS9530 | Engine Installation Kit | — | — |
| 2 | 3906695 | RECTANGULAR RING SEAL | 1 | — |
| 3 | 3910824 | O RING SEAL | 3 | — |
| 4 | 3920773 | SEALING WASHER | 1 | — |
| 5 | 3930906 | VALVE COVER GASKET | 3 | — |
| 6 | 3936876 | RECTANGULAR RING SEAL | 1 | — |
| 7 | 3937706 | OIL DRAIN GASKET | 1 | — |
| 8 | 3939258 | COVER PLATE GASKET | 1 | — |
| 9 | 3942915 | FILTER HEAD GASKET | 1 | — |
| 10 | 3963983 | SEALING WASHER | 2 | — |
| 11 | 4980085 | RECTANGULAR RING SEAL | 1 | — |
| 12 | 5266445 | OIL COOLER CORE GASKET | 1 | — |
| 13 | 5289747 | BANJO CONNECTOR SEAL | 3 | — |
| ——END—— | ||||
Shipping Arrangement | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | SS9621 | Shipping Arrangement | — | — |
| ——END—— | ||||
Starting Motor | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | ST9427 | Starting Motor | — | — |
| 1 | — | MOTOR,STARTING | 2 | — |
| ——END—— | ||||
Turbocharger Arrangement | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB91638 | Turbocharger Arrangement | — | — |
| 2 | 3938152 | INTAKE MANIFOLD COVER GASKET | 1 | — |
| 3 | 4928946 | HEXAGON FLANGE HEAD CAP SCREW | 12 | — |
| 4 | 4928973 | T BOLT CLAMP | 2 | — |
| 5 | 4928974 | T BOLT CLAMP | 2 | — |
| 6 | 4991284 | PLAIN HOSE | 1 | — |
| ——END—— | ||||
Air Intake Manifold | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB91640 | Air Intake Manifold | — | — |
| 2 | 3913915 | INTAKE MANIFOLD COVER | 1 | — |
| ——END—— | ||||
Air Crossover Connection | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB91681 | Air Crossover Connection | — | — |
| 2 | 4991276 | AIR INLET PIPE | 1 | — |
| ——END—— | ||||
Air Crossover Connection | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB91681 | Air Crossover Connection | — | — |
| 2 | 4991276 | AIR INLET PIPE | 1 | — |
| ——END—— | ||||
Exhaust Manifold Mounting | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB9766 | Exhaust Manifold Mounting | — | — |
| 2 | 3929881 | EXHAUST MANIFOLD GASKET | 6 | — |
| 3 | 3944593 | HEXAGON FLANGE HEAD CAP SCREW | 12 | — |
| ——END—— | ||||
Exhaust Manifold | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TB9792 | Exhaust Manifold | — | — |
| 2 | 1 | GASKET,EXHAUST MANIFOLD | — | — |
| 3 | 2 | MANIFOLD,EXHAUST | — | — |
| 4 | 3 | SPACER,MOUNTING | — | — |
| 5 | 4 | SCREW,HEX FLANGE HEAD CAP | — | — |
| 6 | 5 | SEAL,EXHAUST MANIFOLD | — | — |
| 7 | 6 | MANIFOLD,EXHAUST | — | — |
| 8 | 7 | GASKET,EXHAUST MANIFOLD | — | — |
| 9 | 8 | SCREW,HEX FLANGE HEAD CAP | — | — |
| ——END—— | ||||
Thermostat Housing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TH9114 | Thermostat Housing | — | — |
| 2 | 3281246 | LIFTING BRACKET | 1 | — |
| 3 | 3900632 | HEXAGON FLANGE HEAD CAP SCREW | 1 | — |
| 4 | 3923331 | THERMOSTAT HOUSING COVER GASKET | 1 | — |
| 5 | 3926972 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 6 | 5257270 | THERMOSTAT HOUSING | 1 | — |
| ——END—— | ||||
Service Tool | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TO90000 | Service Tool | — | — |
| ——END—— | ||||
Turbocharger Plumbing | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | TP97314 | Turbocharger Plumbing | — | — |
| 2 | 3900630 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3937706 | OIL DRAIN GASKET | 1 | — |
| 4 | 3974113 | FLEXIBLE HOSE | 1 | — |
| 5 | 3975061 | TUR OIL DRAIN TUBE | 1 | — |
| 6 | 3975113 | MALE CONNECTOR | 2 | — |
| ——END—— | ||||
Valve Cover | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | VC9023 | Valve Cover | — | — |
| 2 | 3901895 | FILLER CAP | 1 | — |
| 3 | 3907049 | HEXAGON FLANGE HEAD CAP SCREW | 6 | — |
| 4 | 3928404 | VALVE COVER | 5 | — |
| 5 | 3928405 | VALVE COVER | 1 | — |
| 6 | 3930906 | VALVE COVER GASKET | 6 | — |
| 7 | 3935449 | NOISE ISOLATOR | 6 | — |
| ——END—— | ||||
Engine Coolant Vent | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | WH9131 | Engine Coolant Vent | — | — |
| 2 | 4938322 | PLAIN HOSE COUPLING | 1 | — |
| ——END—— | ||||
Water Inlet Connection | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | WI9226 | Water Inlet Connection | — | — |
| 2 | 3008469 | PIPE PLUG | 1 | — |
| 3 | 3906697 | RECTANGULAR RING SEAL | 1 | — |
| 4 | 3973197 | WATER INLET CONNECTION | 1 | — |
| ——END—— | ||||
Water Inlet Connection | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | WI9701 | Water Inlet Connection | — | — |
| 2 | — | PLUG,THREADED | — | — |
| 3 | — | GASKET,CONNECTION | — | — |
| 4 | — | CONNECTION,WATER INLET | — | — |
| 5 | — | SHAFT,SHUTOFF VALVE | — | — |
| 6 | — | SCREW,HEX FLANGE HEAD CAP | — | — |
| 7 | — | PLUG,THREADED | — | — |
| ——END—— | ||||
Water Pump | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | WP9617 | Water Pump | — | — |
| 2 | 3900227 | HEXAGON HEAD CAP SCREW | 2 | — |
| 3 | 3906698 | RECTANGULAR RING SEAL | 1 | — |
| ——END—— | ||||
Exhaust Outlet Connection | ||||
| No. | Part No. | Part Name | Qty/Eng | Remarks |
| 1 | XS9469 | Exhaust Outlet Connection | — | — |
| 2 | 3093957 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 3 | 3900632 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 4 | 3903990 | HEXAGON FLANGE HEAD CAP SCREW | 2 | — |
| 5 | 3971092 | TUBE BRACE | 1 | — |
| 6 | 3971093 | EXHAUST OUTLET CONNECTION | 1 | — |
| 7 | 4928803 | SPRING HOSE CLAMP | 2 | — |
| 8 | 4928804 | EXHAUST OUTLET CONNECTION GASKET | 1 | — |
| 9 | 4928805 | EXHAUST OUTLET CONNECTION GASKET | 2 | — |
| 10 | 4991528 | HEXAGON FLANGE NUT | 2 | — |
| ——END—— | ||||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
DCEC 6BT5.9-G2-A generator drive engine is a 6-cylinders in line,5.9 liter four-strokes engine with 102mm bore and 120mm stroke.
Equipped with Beiyou PB Pump /GAC Electronic Governor.
Beiyou PB Pump/Fuchuang Electronic Governor, comes with turbocharger.
The prime power for 50HZ generator set (1500 RPM) of DCEC 6BT5.9-G2-A generator drive engine is 96kW.
As part of EMAC, SinoGen also provide complete power supply solutions that powered by DCEC, our ranges of products including open type generator set, silence type generator set, super silence type generator set, mobile trailer, complete power truck and complete power car for railways applications.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of DCEC 6BT5.9-G2-A G-Drive Engine
The cylinder bore adopts a platform mesh honing design, the perfect geometric structure effectively prevents oil leakage. adopts advanced technologies such as new piston ring components and gasket crimping molding to reduce oil loss.
The cylinder block and cylinder head adopt integrated design, which eliminates the occurrence of engine water leakage and oil leakage.
The parts are about 40% less than other similar engines, and the failure rate is greatly reduced.
Forged steel camshaft and crankshaft, high-strength cylinder block design, multiple parts cast on the cylinder block. high rigidity, high pressure resistance, good reliability, and longer service life.
Engine Sale Manual
Installation Drawing
Installation Manual
Operation Manual
Parts Catalogue
